Airtac 6HV Manifold Solenoid Valve 6HV0510M5A200
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0510M5A200 Modular Solenoid Valve Specifications
- Model: 6HV0510M5A200
- Type: 5-port/3-position (Mid-exhaust closed type)
- Port configuration: G1/8 (ISO228/1 standard)
- Mounting interface: ISO 5599/1 modular base
- Operating pressure range: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage specification: AC220V ±10% 50/60Hz
- Coil insulation class: Class F (155℃)
- Response time: ≤18ms (at 0.5MPa)
- Maximum flow rate: 1200 l/min (ANR)
- Seal material: NBR (Nitrile rubber)
- Ambient temperature range: -5℃ to 60℃ (no freeze)
- Protection rating: IP67 (Dust-tight & protected against immersion)
- Weight: 320g ±5% (including manifold base)
- Dimensions: 78mm(L) × 52mm(W) × 34mm(H)
High-density modular valve with multi-functional position control, featuring aluminum alloy body and copper-free piston design for enhanced corrosion resistance. The optimized flow path geometry reduces pressure drop by 15% compared to previous generations. Requires 5μm filtered compressed air with oil mist lubrication (ISO 8573-1:2010 Class 3.4.2).
- Multi-axis pneumatic actuator synchronization systems
- Automated assembly line clamping sequences
- Plastic injection molding machine core-pull mechanisms
- CNC tool changer positioning control
- Semiconductor wafer handling robotics
Installation guidelines:
Maintain horizontal manifold orientation with vibration damping pads.
Use torque-controlled tightening (1.2-1.5N·m for manifold screws).
Allow 20mm clearance above coil for heat dissipation.
Ground resistance ≤100Ω required.
| Property | Property Value |
|---|---|
| sku | 6HV0510M5A200 |
| Port Size | M5 |
| Standard Voltage | AC220V |
