Airtac 6HV Manifold Solenoid Valve 6HV0510M5B050
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0510M5B050 Manifold Solenoid Valve Specifications
- Model: 6HV0510M5B050
- Type: 5/2-way, double solenoid (manifold mount)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–0.9 MPa
- Voltage options: DC24V (±10%), AC110V 50/60Hz, AC220V 50/60Hz
- Flow capacity: 1000 l/min (ANR)
- Response time: ≤20ms (at 0.5MPa)
- Seal material: Heat-resistant NBR (up to 120℃ intermittent)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Protection rating: IP67 (with connector)
- Weight: 320g ±5% (single valve body)
- Dimensions: 68mm(L) × 34mm(W) × 54mm(H) (per valve section)
- Manifold pitch: 18mm (between valve centers)
- Port thread depth: 9mm (minimum engagement)
High-density modular valve designed for multi-valve manifolds in automated systems. Features zero leakage design with double-piston pilot structure for stable switching. Compatible with ISO 15407-1 standard manifold bases. Includes LED operation indicator and surge protection circuitry.
- Automated production line actuator control
- Plastic injection molding machine sequences
- Semiconductor handling equipment
- Multi-axis pneumatic robotics
- High-cycle packaging machinery
Installation note:
Use M5x0.8 mounting screws with 0.6-0.8Nm torque. Maintain 50mm clearance below manifold for maintenance. Requires ISO VG32 or equivalent pneumatic oil lubrication for extended service life.
Critical parameters:
Maximum permissible backpressure 0.1MPa. Do NOT use with silicone-based lubricants. Minimum holding time between switching: 0.5 seconds.
| Property | Property Value |
|---|---|
| sku | 6HV0510M5B050 |
| Port Size | M5 |
| Standard Voltage | DC24V |
