Airtac 6HV Manifold Solenoid Valve 6HV0510M5B200
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0510M5B200 Manifold-Mounted Solenoid Valve Specifications
- Model: 6HV0510M5B200
- Type: 5/2-way mono-stable (spring return)
- Port configuration: M5 threaded manifold base
- Port size: Ø4mm (1/8" equivalent flow)
- Operating pressure: 0.15–1.0 MPa (21.7–145 psi)
- Voltage: DC24V ±10% (coil class H)
- Power consumption: 1.8W (standard), 0.45W (power-saving mode)
- Max flow rate: 650 NL/min (ANR, at 0.5 MPa)
- Response time: ≤15ms (exhaust to actuation)
- Seal material: Heat-resistant NBR (nitrile butadiene rubber)
- Temperature range: -10℃ to 80℃ (no freezing)
- Protection rating: IP67 (dustproof & temporary immersion)
- Weight: 280g ±5% (single valve body)
- Dimensions: 56mm(L) × 34mm(W) × 78mm(H) per station
- Manifold compatibility: Up to 20 stations in series
- Port alignment: ISO 15407-1 standard pattern
High-density manifold valve with integrated silencer and LED status indicator. Features corrosion-resistant aluminum alloy body with hard anodized finish. Designed for multi-valve systems requiring synchronized pneumatic control. Includes surge suppression circuit for coil protection. Requires ISO 8573-1 class 3 compressed air (max 5μm particles).
- Automated assembly line clamping systems
- Multi-axis pneumatic actuator synchronization
- Beverage filling machine valve clusters
- Semiconductor wafer handling robots
- Textile machinery air circuit control
Installation note:
Ensure manifold base flatness ≤0.1mm before assembly. Use torque-controlled wrench
(1.5-2.0 N·m) for valve mounting. Maintain 50mm clearance below manifold for tubing.
| Property | Property Value |
|---|---|
| sku | 6HV0510M5B200 |
| Port Size | M5 |
| Standard Voltage | DC24V |
