Airtac 6HV Manifold Solenoid Valve 6HV0510M5C050
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0510M5C050 Manifold Solenoid Valve Specifications
- Model: 6HV0510M5C050
- Type: 5/2-way double solenoid pilot-operated (dual-coil latching)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Seal material: NBR (Nitrile), optional FKM available
- Temperature range: -5℃ to 60℃ (23℉ to 140℉)
- Response time: ≤25ms (open), ≤30ms (close)
- Flow capacity: Cv=0.53 (Kv=0.46)
- Protection rating: IP67 (coil), IP40 (valve body)
- Weight: 320g (11.3 oz) ±5%
- Dimensions: 75mm(L) × 34mm(W) × 55mm(H) (2.95" × 1.34" × 2.17")
- Installation: Multi-station manifold mounting (ISO 15407-1 standard)
- Electrical connection: DIN43650 Form A with LED indicator
High-density modular valve optimized for multi-valve manifold systems, featuring twin-coil latching for energy-efficient operation. The anodized aluminum body with stainless steel piston ensures corrosion resistance in humid environments. Designed for 10 million cycle durability with ≤1.0W holding power consumption (per coil). Requires 5μm filtered air with lubrication not mandatory.
- Automated assembly line sequencing systems
- Multi-axis pneumatic actuator control in CNC machinery
- Plastic injection molding machine clamping units
- Automotive welding robot end-effector controls
- Food-grade pneumatic systems (with optional FKM seals)
Installation guidelines:
Maximum 20-valve manifold configuration recommended. Maintain 0.5mm alignment tolerance during manifold stacking.
Use M5×16 mounting screws at 0.4Nm torque. Allow 15mm vertical clearance above coils for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 6HV0510M5C050 |
| Port Size | M5 |
| Standard Voltage | AC 110V |
