Airtac 6HV Manifold Solenoid Valve 6HV0510M5F050
Genuine AirTAC manifold solenoid valve, order code 6HV0510M5F050 from the 6HV range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- Body and port0500 series, M5
- FunctionSingle solenoid (10)
- Voltage and leadDC12V (F), 0.5 m lead
- Function5/2 and 5/3-way manifold solenoid valve
- OperationPilot operated (solenoid)
- 0500 seriesM5 supply and outlets · 3.4 mm² (Cv 0.2), 5/3-way 2.2 mm² (Cv 0.13)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 6HV Manifold Solenoid Valve 6HV0510M5F050
This code combines the compact 0500 body of the AirTAC 6HV series with a single solenoid 5/2 function: M5 supply and outlets, a 3.4 mm2 orifice (Cv 0.2), and a DC12V coil (voltage code F) on a 0.5 m lead that draws 0.7 W. The valve is pilot operated with a plug-in connector, class F insulation, and responds in 0.05 s or less; when the coil de-energizes, the spring returns the spool to its rest position so the actuator always goes back to a defined state.
Like every 6HV valve it clips onto a DIN rail manifold with common supply and exhaust and can be taken off or swapped in any number. It runs on 0.15 to 0.8 MPa (21 to 114 psi) of air filtered to 40 um, tolerates proof pressure of 1.2 MPa (175 psi), works from -20 to +70 C, and needs no lubrication. AirTAC discontinued the 6HV series in January 2026 and has not named a replacement; request a quote with the order code so we can confirm whether it can still be supplied.
Airtac 6HV Manifold Solenoid Valve 6HV0510M5F050 Technical Specifications
| Order code | 6HV0510M5F050 |
|---|---|
| Product | Manifold Solenoid Valve |
| Body and port | 0500 series, M5 |
| Function | Single solenoid (10) |
| Voltage and lead | DC12V (F), 0.5 m lead |
| Function | 5/2 and 5/3-way manifold solenoid valve |
|---|---|
| Operation | Pilot operated (solenoid) |
| 0500 series | M5 supply and outlets · 3.4 mm² (Cv 0.2), 5/3-way 2.2 mm² (Cv 0.13) |
| 100 series | M5 or PT1/8 supply and outlets · 8.9 mm² (Cv 0.52), 5/3-way 8.0 mm² (Cv 0.47) |
| Fluid | Air (filtered by 40 µm element) |
| Operating pressure | 0.15 – 0.8 MPa (21 – 114 psi); 5/3-way 0.2 – 0.8 MPa |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to +70 °C |
| Max frequency | 5 cycles/s; 5/3-way 3 cycles/s |
| Body | Aluminum alloy |
| Lubrication | Not required |
| Coil voltages | AC220V, AC110V, DC24V, DC12V |
| Coil power | AC 1.1 VA · DC 0.7 W |
| Voltage tolerance | AC +15% / -10%, DC ±10% |
| Insulation | Class F, dust-protected |
| Electrical entry | Plug-in connector |
| Response time | 0.05 s or less |
Source: AirTAC 6HV series datasheet (airtac.com discontinued products), specifications and ordering code. AirTAC lists the 6HV series as discontinued (January 2026).
How to choose
Within the 6HV ordering table, this DC12V single solenoid valve with a 0.5 m lead (050) sits beside 6HV0510M5F200, identical except for a 2.0 m lead, and beside the double solenoid 6HV0520M5A050, which holds its last position instead of springing back. If M5 flow (Cv 0.2) is too small for the actuator, step up to the 100 series body (code 1) with 8.9 mm2 / Cv 0.52 and a 1/8 inch PT option; for a mid-position function, look at the 5/3 codes 30C, 30E or 30P instead of 10. Voltage alternatives to F (DC12V) are A (AC220V), B (DC24V) and C (AC110V).
Applications
Battery-powered 12V fixtures
A DC12V coil drawing 0.7 W suits small actuator circuits fed from a 12 V supply, with the spring return giving a safe retract if power is cut.
Bench and fixture manifolds
Clip several 0500-body valves onto one DIN rail for a compact M5 manifold with common supply and exhaust, then swap any single valve without disturbing the others.
Small pick-and-place grippers
The M5 ports and Cv 0.2 orifice match light gripper and cylinder loads, while the 0.05 s or faster response keeps short cycling accurate.
FAQ
What are the key figures of the 6HV0510M5F050?
0500 series body, M5 supply and outlets, 5/2 single solenoid (spring return), flow 3.4 mm2 (Cv 0.2), operating pressure 0.15 to 0.8 MPa (21 to 114 psi), proof pressure 1.2 MPa (175 psi), temperature -20 to +70 C, DC12V coil at 0.7 W with a 0.5 m lead, plug-in connector, response 0.05 s or less, air filtered to 40 um, no lubrication required.
Is this valve still available from AirTAC?
No. AirTAC discontinued the 6HV series in January 2026 and has not named a replacement series. Submit a quote request with the order code 6HV0510M5F050 and we will confirm whether this exact valve can still be supplied.
