Airtac 6HV Manifold Solenoid Valve 6HV0520M5B050
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV Series Modular Solenoid Valve 6HV0520M5B050 Technical Details
- Full model code: 6HV0520M5B050 (ISO 15407-1 compliant)
- Valve type: 5-port/2-position (5/2-way) with center closed position
- Port thread: G1/8 (ISO 228-1) with M5 sub-base connection
- Effective sectional area: 20mm² (Cv=0.32)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC24V (±10%), AC110V 50/60Hz, AC220V 50Hz
- Coil insulation class: Class F (155℃) with thermal overload protection
- Weight: 320g ±5% (including manifold base)
- Dimensions: 56mm(L) × 42mm(W) × 78mm(H)
- Seal material: FKM (Fluoroelastomer) standard / optional NBR
- Ambient temperature: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: 2.2W (DC24V) / 3.5VA (AC)
- Response time: ≤15ms (exhaust to full actuation)
- Protection grade: IP67 (coil) / IP40 (valve body)
- Cycle rate: ≤5Hz (with lubricated air)
High-flow modular solenoid valve with manual override and position indicator. Features stainless steel plunger and reinforced PPS body for chemical resistance. Designed for multi-station manifold mounting with ISO 15407-1 compliant sub-base. Requires 5μm filtered compressed air with 1-10 cSt viscosity oil mist (optional).
- Multi-axis pneumatic actuator control in packaging lines
- Clamping sequence control in automotive welding fixtures
- Batch processing systems requiring manifold-mounted valves
- Food-grade pneumatic circuits (with NSF-H1 lubricant option)
- High-cycle printing press air cylinder control
Installation guidelines:
Mount horizontally with manifold surface flatness ≤0.1mm.
Use torque-limited driver (1.2-1.5N·m for M5 screws).
Maintain 15mm clearance below for tube routing.
Perform monthly manual cycling if operated intermittently.
Critical note:
Not compatible with phosphate ester fluids or chlorinated lubricants.
Always install downstream moisture separator when ambient humidity exceeds 80% RH.
| Property | Property Value |
|---|---|
| sku | 6HV0520M5B050 |
| Port Size | M5 |
| Standard Voltage | DC24V |
