Airtac 6HV Manifold Solenoid Valve 6HV0520M5B200
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV Series Manifold Solenoid Valve 6HV0520M5B200 Technical Details
- Model Code Breakdown: 6HV-0520-M5-B-200
- Valve Type: 5-port 3-position (closed center)
- Operation Method: Electromagnetic pilot-operated with spring return
- Port Thread: PT1/4 (BSPP) with M5 subminiature ports
- Operating Pressure Range: 0.15~0.8 MPa (21.7~116 PSI)
- Voltage Variations: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Flow Coefficient (Cv): 0.6 (Kv=0.52)
- Seal Material: Nitrile Butadiene Rubber (NBR) standard (FKM optional)
- Ambient Temperature: -5℃ to 60℃ (no freeze)
- Response Time: ≤15ms (open), ≤20ms (close) at rated voltage
- Electrical Protection: Class F insulation, surge suppression
- Mechanical Life: ≥50 million cycles
- Weight: 450g ±5% (excluding cables)
- Dimensions: 52mm(W) × 44mm(H) × 83mm(L) per unit
- Manifold Capacity: Up to 20 valves per manifold bank
- Port Alignment: ISO 5599-1 standard pattern
- Protection Rating: IP65 (coil), IP40 (valve body)
Modular solenoid valve designed for high-density manifold mounting in multi-valve pneumatic systems. Features integrated air passage design with zero-leakage spool structure and copper-free aluminum alloy body. The 3-position configuration allows mid-position exhaust closure for cylinder holding. Optimized pilot chamber reduces minimum operating pressure by 30% compared to previous generations.
- Multi-axis pneumatic actuator synchronization in assembly robots
- Plastic injection molding machine clamp controls
- Textile machinery air circuit distribution blocks
- Semiconductor wafer handling vacuum/pressure systems
- Beverage filling line multi-nozzle control
Installation Protocol:
Use torque-controlled mounting (1.5-2.0N·m) with included alignment pins.
Maintain 15mm clearance below manifold for heat dissipation. Pre-flush pipelines
with 0.3MPa air for 30s before commissioning. For multi-valve stacks, install
endplate dampers (sold separately) to reduce water hammer effect.
| Property | Property Value |
|---|---|
| sku | 6HV0520M5B200 |
| Port Size | M5 |
| Standard Voltage | DC24V |
