Airtac 6HV Manifold Solenoid Valve 6HV0520M5F050
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV Series Manifold Solenoid Valve 6HV0520M5F050 Technical Details
- Model Code: 6HV0520M5F050
- Valve Type: 5/2-way monostable (single solenoid)
- Port Configuration: M5 threaded ports (G1/8 equivalent flow)
- Operating Pressure Range: 0.1–0.9 MPa (14.5–130.5 PSI)
- Voltage Specifications: DC24V (±10%) with DIN43650 connector
- Power Consumption: 1.6W (coil class F insulation)
- Weight: 320g ±5% (including manifold base)
- Dimensions: 52mm(W) × 20mm(H) × 68mm(L) per valve section
- Seal Material: Heat-resistant NBR (Nitrile) compound
- Temperature Range: -5℃ to 80℃ (with dew point -25℃ below ambient)
- Flow Capacity: Cv 0.21 (Kv 0.18) at 0.5 MPa
- Response Time: ≤15ms (exhaust to full flow)
- Protection Class: IP67 (dust/immersion protection)
- Manifold Type: ISO 15407-2 compliant modular design
- Max Operating Frequency: 5Hz (300 cycles/min)
High-density modular valve optimized for multi-station pneumatic systems requiring centralized control. Features zero-pressure differential activation and auto-pressure compensation for stable operation in fluctuating line pressures. The copper-free aluminum alloy body meets RoHS3 compliance, with integrated surge protection diodes for electrical safety.
- Multi-axis robotic end effector control
- Pharmaceutical blister packaging machines
- PCB handling vacuum/pressure systems
- Beverage canning line diverters
- Lithium battery formation equipment
Installation Protocol:
Maximum 20-valve manifold length recommended. Use torque-limited driver
(0.8–1.2Nm) for manifold screws. Always purge system for 30s before
energizing coils to remove installation debris.
| Property | Property Value |
|---|---|
| sku | 6HV0520M5F050 |
| Port Size | M5 |
| Standard Voltage | AC12V |
