Airtac 6HV Manifold Solenoid Valve 6HV0520M5F200
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV Series Modular Solenoid Valve 6HV0520M5F200 Technical Details
- Model: 6HV0520M5F200
- Type: 5/2-way monostable (single solenoid) with manual override
- Port configuration: 1/4" BSPP (G1/4) with M5 sub-ports for pilot air
- Operating pressure range: 0.15-1.0 MPa (21.7-145 PSI)
- Voltage variants: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Coil power: 2.2W (AC), 2.8W (DC) with Class F insulation
- Response time: ≤15ms (exhaust to full flow)
- Flow capacity: 850 l/min (Cv=1.3 at 0.5MPa)
- Seal materials: HNBR main seals, FKM secondary seals
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Protection class: IP67 (coil), IP40 (valve body)
- Weight: 520g ±3% (including manifold base)
- Dimensions: 148mm(L) × 98mm(W) × 42mm(H) (single valve stack)
- Port thread depth: 12mm (main ports), 8mm (pilot ports)
- Expected service life: 50 million cycles (clean air conditions)
This modular valve features a rugged aluminum alloy body with nickel-plated brass cores, designed for multi-valve manifold configurations. The 6HV0520M5F200 model integrates quick-connect DIN43650 coil terminals and status indicator LEDs. Its low-hysteresis design maintains stable operation in vibration-prone environments (up to 10-55Hz frequency range). Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Multi-station pneumatic fixture control in CNC machining centers
- High-speed sorting systems with multi-actuator coordination
- Plastic injection molding machine clamp sequences
- Automated assembly line tooling changers
- Semiconductor handling equipment vacuum/pressure switching
Installation guidelines:
Mount on ISO 15407-1 compliant manifold rails using M4 mounting screws (2.5Nm torque limit).
Maintain minimum 20mm clearance below valve for heat dissipation. Use copper-free lubricants
if required. Perform monthly air filter drain checks in high-humidity environments.
- Integrated surge suppression for voltage spike protection
- Reverse polarity protection for DC models
- LED status indicator with 270° visibility
- Tool-free manual override with position lock
- Compatible with fieldbus interfaces via optional adapter plates
| Property | Property Value |
|---|---|
| sku | 6HV0520M5F200 |
| Port Size | M5 |
| Standard Voltage | AC12V |
