Airtac 6HV Manifold Solenoid Valve 6HV0530CM5B050
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0530CM5B050 Manifold Solenoid Valve Specifications
- Model: 6HV0530CM5B050
- Type: 5/3-way closed center (solenoid pilot operated)
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Weight: 0.85 kg (1.87 lbs)
- Dimensions: 135mm(L) × 24mm(W) × 48mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -10℃ to 70℃ (14°F to 158°F)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Flow coefficient (Cv): 1.8
- Response time: ≤15ms (exhaust to full flow)
- Port configuration: 5 ports (P, A, B, EA, EB) / 3 positions
- Protection rating: IP67 (dustproof and temporary immersion protection)
- Manual override: Built-in emergency push button
- Mounting type: ISO 15407-1 compliant manifold system
High-density manifold-mounted valve with central exhaust design, optimized for multi-valve systems requiring precise directional control. Features corrosion-resistant aluminum alloy body with PTFE piston seals for reduced friction. Includes LED status indicator and surge protection circuit. Requires ISO 8573-1 Class 3 compressed air (max 5μm particle size).
- Multi-axis pneumatic actuator control systems
- Automated assembly line clamping mechanisms
- Plastic injection molding machine sequencing
- Semiconductor handling robotics
- CNC tool changers with dual-action cylinders
Installation note:
Requires minimum 10mm spacing between valve banks for heat dissipation.
Use torque-limited driver (0.7-1.2 N·m) when mounting to manifold base.
Perform weekly exhaust port cleaning in high particulate environments.
| Property | Property Value |
|---|---|
| sku | 6HV0530CM5B050 |
| Port Size | M5 |
| Standard Voltage | DC24V |
