Airtac 6HV Manifold Solenoid Valve 6HV0530CM5B200
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV Series Manifold-Mounted Solenoid Valve 6HV0530CM5B200 Technical Details
- Full model designation: 6HV0530CM5B200
- Valve type: 5-port 3-position closed center (with pressure retention)
- Port configuration: 1/4" BSPP (G1/4) with ISO 15407-1 compliant manifold interface
- Operating pressure range: 0.05–1.0 MPa (7-145 PSI)
- Flow capacity: 650 l/min (Cv=1.25) at 0.5 MPa
- Voltage variants: DC24V (±10%) with DIN43650 Form B coil connector
- Coil insulation class: Class F (155℃)
- Seal materials: NBR (standard), optional Viton for high-temp applications
- Ambient temperature range: -5℃ to 60℃ (with NBR seals)
- Weight: 480g ±3% (single valve without manifold)
- Dimensions: 53mm(W) × 54mm(H) × 25mm(D) per valve section
- Response time: ≤30ms (energize), ≤20ms (de-energize)
- Power consumption: 2.8W (continuous duty)
- Protection rating: IP67 (coil), IP40 (valve body)
- Manual override: Built-in mechanical override button
Modular manifold valve designed for multi-station pneumatic systems requiring centralized control. Features zero-pressure differential start capability and gold-plated terminals for reliable connectivity. The optimized spool structure reduces switching hysteresis by 30% compared to previous generations. Compatible with ISO G1/4 manifold bases for unlimited station expansion.
- Multi-axis pneumatic actuator synchronization in packaging lines
- Plastic injection molding machine core-pull sequences
- Automated welding fixture clamping systems
- Beverage filling station pressure regulation
- Semiconductor handling robot end-effector controls
Installation requirements:
Maximum manifold stack height 12 valves. Use M5×16mm mounting screws with 0.8-1.2Nm torque.
Maintain minimum 50mm clearance below valve for tubing connections. Lubricate seals with PST-1 grease.
0.5MPa @60℃ → 0.8MPa @40℃ → 1.0MPa @20℃ (derate 0.02MPa/℃ above 40℃)
| Property | Property Value |
|---|---|
| sku | 6HV0530CM5B200 |
| Port Size | M5 |
| Standard Voltage | DC24V |
