Airtac 6HV Manifold Solenoid Valve 6HV0530CM5C200
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0530CM5C200 Manifold-Mounted Solenoid Valve Specifications
- Model Code Breakdown: 6HV (Series) | 05 (Port Size 1/4") | 30 (3/2-way) | CM (Coil Voltage Code) | 5 (Lead Wire Length 500mm) | C200 (Special Configuration)
- Type: 3/2-way normally closed (Direct-acting with forced pilot)
- Port Size: G1/4 (ISO228-1 standard)
- Operating Pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Max Flow Rate: 850 L/min (Cv=1.2 at 0.5 MPa)
- Voltage Options: CM5C200 = DC24V (±10%) / Alternative variants: AC110V(50/60Hz), AC220V(50/60Hz)
- Power Consumption: 1.6W (DC) / 3.2VA (AC)
- Response Time: ≤15ms (On/Off cycle)
- Seal Material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Temperature Range: -10℃ to 80℃ (14°F to 176°F)
- Fluid Compatibility: Compressed air (Lubricated or non-lubricated)
- Protection Rating: IP67 (Dust-tight & temporary immersion)
- Mounting: ISO 15407-1 compliant manifold interface
- Weight: 520g ±5% (Valve body only) / 680g with manifold base
- Dimensions: 45mm(W) × 55mm(H) × 98mm(L) (Manifold stack width per valve)
- Port Thread Depth: 12mm (Minimum engagement depth)
High-density manifold valve with zero leakage design, featuring anti-vibration coil construction and gold-plated terminals. Optimized for multi-station pneumatic systems requiring synchronized actuation. Includes LED status indicator and surge protection diode. Requires 5μm filtered compressed air with max 50mg/m³ oil content.
- Multi-axis robotic gripper control systems
- Plastic injection molding machine ejectors
- Automated assembly line clamping units
- Semiconductor wafer handling equipment
- Textile machinery air-jet looms
Installation Protocol:
Torque manifold screws to 1.2N·m in crisscross pattern. Maintain 0.5mm gap between adjacent valves for thermal expansion. Use PTFE tape on port threads with 1.5-wrap maximum. Perform 500-cycle burn-in test before full operation.
| Property | Property Value |
|---|---|
| sku | 6HV0530CM5C200 |
| Port Size | M5 |
| Standard Voltage | AC 110V |
