Airtac 6TV Solenoid Valve 6TV0500M2F
$8.34
Regular price
$15.84
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
6TV0500M2F
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Plug-in electrical connection design allows horizontal and vertical terminal mounting orientations to be freely interchangeable;
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M2F Solenoid Valve Technical Specifications
- Model: 6TV0500M2F
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–1.0 MPa
- Maximum flow rate: 750 L/min (ANR)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155°C)
- Power consumption: 2.8W (DC), 3.5VA (AC)
- Weight: 350g ±5% (excluding accessories)
- Dimensions: 98mm(L) × 44mm(W) × 44mm(H)
- Seal materials: HNBR (hydrogenated nitrile) for enhanced oil resistance
- Temperature tolerance: -10℃ to 80℃ (non-freezing)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Protection standard: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with metal seal option, featuring anti-vibration coil design for industrial environments. The pilot-operated mechanism enables reliable switching under fluctuating pressures. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
Primary Applications:
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery double-acting actuator control
- Plastic injection molding machine clamp systems
- Automated material handling equipment
- Semiconductor wafer transfer mechanisms
Installation guidelines:
Mount in vibration-damped position using M4 mounting screws (torque ≤1.2N·m).
Maintain minimum 20mm clearance below valve for exhaust flow. Lubricate seals
with ISO VG32 turbine oil if used in dry air systems.
Service advisory:
Replace coil lead wires every 5 million cycles in high-duty applications.
Use 0.5-0.6MPa test pressure for seat leakage checks (max allowable: 10 bubbles/min).
| Property | Property Value |
|---|---|
| sku | 6TV0500M2F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
