Airtac 6V Solenoid Valve 6V0520M5C200
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0520M5C200 Solenoid Valve Technical Details
- Model: 6V0520M5C200
- Type: 5/2-way monostable (direct-acting)
- Port size: M5 (ISO 228 G1/8 equivalent)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Current draw: DC24V: 0.35A | AC110V: 0.12A | AC220V: 0.06A
- Weight: 230g ±5% (with connector)
- Dimensions: 52mm(L) × 34mm(W) × 67mm(H) (excluding mounting brackets)
- Flow capacity: 700 l/min (ANR) at 0.5MPa
- Seal material: Heat-resistant NBR (Nitrile) -70℃ to 120℃
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Response time: ≤15ms (exhaust to operation)
- Port thread depth: 9mm (minimum engagement)
- Protection class: IP67 (dust/water resistant)
- Service life: ≥10 million cycles (under rated conditions)
High-speed 5-port pneumatic valve engineered for industrial automation sequences. Features dual-coil latching design with manual override capability. The aluminum alloy body with hard anodizing resists chemical corrosion, while the low-hysteresis spool design ensures precise cylinder control. Requires ISO 8573-1 class 3 compressed air (max 50mg/m³ oil content).
- Pick-and-place robot end effectors
- Plastic injection molding machine ejectors
- Textile machinery tension control systems
- Automotive assembly line clamping units
- Bottle capping machine pneumatic circuits
Maintenance protocol:
Lubricate spool monthly with ISO VG32 turbine oil if used in dry air systems.
Avoid axial side-loading during piping - use flexible nylon tubing for last
15cm connections. Minimum 5mm vibration gap required between valve and mounting surface.
| Property | Property Value |
|---|---|
| sku | 6V0520M5C200 |
| Port Size | M5 |
| Standard Voltage | AC 110V |
