Airtac 6V Solenoid Valve 6V230E06C200
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V230E06C20C0 5/3-Way Solenoid Valve Technical Details
- Full model code: 6V230E06C20C0 (with DIN connector)
- Valve type: 5-port 3-position (center closed position)
- Port configuration: 2 exhaust ports + 2 cylinder ports + 1 supply port
- Thread standard: G1/8 (ISO228-1) with 14mm hex wrench size
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Flow capacity: 1200 l/min (Cv=1.2) at 0.5 MPa
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Ambient temperature: -5℃ to 80℃ (no freeze condensation)
- Weight: 0.53kg ±5% (including coil)
- Body dimensions: 110mm(L) × 50mm(W) × 60mm(H)
- Seal material: High-grade HNBR (hydrogenated nitrile)
- Electrical protection: IP65 (dust-tight & water jet resistant)
- Power consumption: 1.8W (DC)/3.5VA (AC)
- Manual override: Built-in emergency manual operator
Industrial-grade mid-size solenoid valve with center-block function for precise directional control in pneumatic circuits. Features brass main body with anodized aluminum coil housing for corrosion resistance. The dual-pressure control design allows bi-directional cylinder movement with position holding capability. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Automated assembly line clamping mechanisms
- Plastic injection molding machine ejectors
- CNC tool changers with position hold requirements
- Material handling systems with safety interlocks
- Textile machinery with multi-position cylinder control
Installation guidelines:
Mount in vibration-free environment using M4 mounting screws (max torque 1.2N·m).
Maintain ≥20mm clearance below valve for condensate drainage.
Always install upstream 5μm filter regulator.
For horizontal mounting, orient coil vertically upward.
| Property | Property Value |
|---|---|
| sku | 6V230E06C200 |
| Port Size | PT1/8 |
| Standard Voltage | AC 110V |
