Airtac 7V-F Solenoid Valve Manifold 7V0500M7F
2、Centralized air inlet/exhaust ports and integrated wiring simplify troubleshooting during maintenance:
3、Flexible modular configuration with expandable design - Allows arbitrary combination and expansion of connected directional control valves quantity;
Category: Solenoid Valve Bases , Brand: AirTAC , Series: 7V-F
AirTAC 7V-F Solenoid Valve Base 7V0500M7F Technical Specifications
- Model: 7V0500M7F
- Type: Modular DIN-style manifold base (ISO 15407-1 compliant)
- Port configuration: 5/2-way function
- Port size: G1/8 (ISO228/1 standard)
- Maximum operating pressure: 1.0 MPa
- Minimum operating pressure: 0.15 MPa
- Voltage compatibility: Universal socket for 7V-series coils (DC12V/24V/AC110V/220V)
- Flow capacity: 750 l/min (ANR)
- Seal material: HNBR rubber (hydrogenated nitrile)
- Temperature range: -10℃ to 80℃ (no icing)
- Weight: 348g ±5g
- Dimensions: 80mm(L) × 45mm(W) × 30mm(H)
- Mounting pattern: 40mm DIN rail spacing
- Surface treatment: Anodized aluminum body with nickel-plated ports
- Protection rating: IP65 (coil installed)
High-density modular base featuring multi-chamber flow paths with optimized Cv value, designed for multi-valve stacking in centralized pneumatic control systems. The staggered port arrangement reduces air turbulence and features built-in silencer grooves. Compatible with ISO 15407-compliant subplates and supports up to 20,000,000 cycles at rated pressure.
- Automated assembly line valve clusters
- Plastic injection molding machine controls
- Textile machinery pneumatic circuits
- Semiconductor handling equipment
- Multi-axis pneumatic actuator systems
Installation protocol:
Use M5×16mm mounting screws with 0.8-1.2Nm torque.
Apply sealant (LOCTITE 545) on threaded ports.
Maximum stack height: 12 units with intermediate supports.
Perform pressure decay test after installation.
| Property | Property Value |
|---|---|
| sku | 7V0500M7F |
