Airtac 7V-F Solenoid Valve Manifold 7V100M1F
2、Centralized air inlet/exhaust ports and integrated wiring simplify troubleshooting during maintenance:
3、Flexible modular configuration with expandable design - Allows arbitrary combination and expansion of connected directional control valves quantity;
Category: Solenoid Valve Bases , Brand: AirTAC , Series: 7V-F
AirTAC 7V-F Series Valve Base 7V100M1F Technical Details
- Model: 7V100M1F (Universal base for 7V-F series valves)
- Compatible valve type: 5/2-way, 5/3-way, 4V-series manifold valves
- Port configuration: 5 ports (P, A, B, R, S) with 1/4" NPT threads
- Maximum pressure: 1.0 MPa (145 psi)
- Minimum operating pressure: 0.2 MPa (29 psi)
- Flow capacity: 750 Nl/min (Cv=1.3)
- Mounting pattern: ISO 5599-1 standard
- Body material: Reinforced black PBT resin
- Seal material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Temperature range: -10℃ to 90℃ (14°F to 194°F)
- Weight: 220g ±5% (without mounted valves)
- Dimensions: 76mm(L) × 34mm(W) × 50mm(H)
- Surface finish: UL94 V-0 flame retardant rating
- Electrical connection: DIN43650 Form A compatible
Modular valve base engineered for multi-valve stacking in complex pneumatic systems. Features integrated silencer pockets and auto-bleed function for rapid pressure release. The symmetrical design allows left/right manifold connections with optional end plates (7V-EM). Includes built-in pilot air passages to simplify tubing.
- Automated assembly line clamping systems
- Plastic injection molding machine controls
- Robotic arm end-effector manifolds
- Semiconductor wafer handling equipment
- Multi-station pneumatic testing rigs
Installation protocol:
Use torque-controlled tightening (0.7-0.9 N·m) for valve mounting screws.
Apply Loctite 243 threadlocker on manifold joints. Maintain 0.3mm gap between
stacked bases for thermal expansion. Requires ISO 8573-1 Class 3 compressed air.
- 7V-EM end plates for manifold termination
- 7V-PS series pressure sensors
- 7V-CV check valve modules
- ISO 15407-2 compliant valves
| Property | Property Value |
|---|---|
| sku | 7V100M1F |
