Airtac 7V-F Solenoid Valve Manifold 7V100M2F
2、Centralized air inlet/exhaust ports and integrated wiring simplify troubleshooting during maintenance:
3、Flexible modular configuration with expandable design - Allows arbitrary combination and expansion of connected directional control valves quantity;
Category: Solenoid Valve Bases , Brand: AirTAC , Series: 7V-F
AirTAC 7V-F Series Valve Base 7V100M2F Technical Specifications
- Model: 7V100M2F
- Type: 5/2-way pneumatic valve base (solenoid pilot-operated)
- Port size: G1/8 (ISO standard Rc1/8)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Compatible voltage: Supports multiple coil voltages (DC12V/24V/AC110V/220V via matched solenoid)
- Flow capacity: 750 l/min (ANR) at 0.5 MPa
- Weight: 320g ±5g
- Dimensions: 100mm(L) × 50mm(W) × 40mm(H)
- Seal material: High-grade HNBR (Hydrogenated Nitrile) for oil/fuel resistance
- Temperature range: -20℃ to 80℃ (non-freezing conditions)
- Port thread depth: 12mm (minimum engagement depth 9mm)
- Mounting pattern: ISO 5599-1 standard modular design
- Surface treatment: Black anodized aluminum body
- Protection rating: IP67 (dustproof and temporary immersion resistant)
Modular valve base engineered for high-cycle industrial automation systems, featuring low-pressure loss design with optimized flow paths. The hardened aluminum construction withstands vibration while maintaining dimensional stability. Integrated silencer pad mounting slots and color-coded port indicators (A/B/P/R/S) enable rapid maintenance. Compatible with all 7V-F series valves and most ISO 5599-1 compliant manifolds.
- High-speed packaging machinery sequencing
- Robotic arm end-effector control
- CNC machine tool clamping systems
- Plastic injection molding ejectors
- Automotive assembly line actuators
- Food processing pneumatic circuits (requires food-grade lubrication)
Installation protocol:
Use torque-controlled wrench at 2.5–3.0 N·m for manifold mounting.
Apply thread sealant only on male ports (not required for face seals).
Maintain 20mm clearance below base for manifold heat dissipation.
