Airtac 7V-F Solenoid Valve Manifold 7V100M3F
2、Centralized air inlet/exhaust ports and integrated wiring simplify troubleshooting during maintenance:
3、Flexible modular configuration with expandable design - Allows arbitrary combination and expansion of connected directional control valves quantity;
Category: Solenoid Valve Bases , Brand: AirTAC , Series: 7V-F
AirTAC 7V-F Series Valve Base 7V100M3F Technical Details
- Model: 7V100M3F (7V-F Series Modular Base)
- Compatible Valves: Designed for 10mm manifold width valves
- Port Configuration: 3-position (ISO 5599-1 standard)
- Port Thread Size: G1/8 (BSPP) / 1/4"-18 NPT optional
- Max Operating Pressure: 1.0 MPa (145 psi)
- Temperature Range: -5℃ to 80℃ (with NBR seals)
- Material: Glass fiber reinforced PA66 (30% GF)
- Weight: 0.28 kg (including mounting hardware)
- Dimensions: 60mm(W) × 30mm(H) × 50mm(D)
- Seal Compatibility: Works with NBR, FKM, or EPDM seals
- Mounting: DIN rail compatible (TS35/7.5/15) or direct screw fixing
- Electrical Connection: Built-in 10-pin plug socket (DIN 43650 Form C)
- Vibration Resistance: 10-55Hz @ 1.5mm amplitude
Modular valve base engineered for multi-valve stacking in compact pneumatic systems. Features integrated air passageways for simplified manifold assembly and reduced leakage points. The flame-retardant polymer construction withstands industrial environments while maintaining precise alignment for coil connections.
- Centralized control panels for injection molding machines
- Automated assembly line valve clusters
- Textile machinery with sequenced pneumatic actuators
- Multi-zone packaging equipment requiring grouped valve control
- Laboratory automation systems with space constraints
Installation Protocol:
Apply 3-5Nm torque during manifold stacking. Use only copper-free anti-seize compound on threads.
For vertical installations, orient identification label upward for service accessibility.
