Airtac 7V-F Solenoid Valve Manifold 7V100M4F
$12.52
Regular price
$20.02
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
7V100M4F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Enables modular valve manifold integration in common porting direction, achieving space-saving design and cost efficiency:
2、Centralized air inlet/exhaust ports and integrated wiring simplify troubleshooting during maintenance:
3、Flexible modular configuration with expandable design - Allows arbitrary combination and expansion of connected directional control valves quantity;
Category: Solenoid Valve Bases , Brand: AirTAC , Series: 7V-F
Installation protocol:
Align manifold bases within 0.5° parallelism during multi-unit stacking.
Use torque-limited driver (0.8-1.2Nm) for terminal screws.
Apply thread sealant only on male ports, never on manifold mating surfaces.
2、Centralized air inlet/exhaust ports and integrated wiring simplify troubleshooting during maintenance:
3、Flexible modular configuration with expandable design - Allows arbitrary combination and expansion of connected directional control valves quantity;
Category: Solenoid Valve Bases , Brand: AirTAC , Series: 7V-F
AirTAC 7V-F Series Valve Manifold Base 7V100M4F Technical Details
- Model: 7V100M4F
- Type: Modular pneumatic valve manifold base (4-station)
- Mounting Style: DIN rail TS35 or panel mounting
- Port Configuration: 1/4" NPT (M5 optional)
- Max Operating Pressure: 1.0 MPa (145 psi)
- Proof Pressure: 1.5 MPa
- Flow Capacity: 750 Nl/min (CV=1.2)
- Port Alignment: 18mm pitch horizontal manifold
- Voltage Compatibility: AC/DC (varies by attached solenoids)
- Seal Material: HNBR (Hydrogenated Nitrile) for -20℃ to 120℃
- Weight: 520g ±3% (bare base)
- Dimensions: 100mm(L) × 40mm(W) × 82mm(H)
- Housing Material: Reinforced PBT with UL94 V-0 rating
- Terminal Type: Plug-in spring terminals (2.5mm² wire capacity)
- Vibration Resistance: 10-55Hz with 1.5mm amplitude
High-density modular base for creating compact valve clusters in automation systems. Features integrated air passage design with leak-proof membrane seals and tool-free valve mounting. The staggered port arrangement prevents hose interference during dense installations.
Typical Applications:
- Multi-axis pneumatic actuator control in assembly robots
- Centralized air distribution in packaging machinery
- Modular control stations for semiconductor handling equipment
- Mobile hydraulic/pneumatic hybrid systems
- Multi-zone vacuum gripping systems
Installation protocol:
Align manifold bases within 0.5° parallelism during multi-unit stacking.
Use torque-limited driver (0.8-1.2Nm) for terminal screws.
Apply thread sealant only on male ports, never on manifold mating surfaces.
Compatible Components:
- 7V Series Solenoids: 7V230, 7V220, 7V210 (single/double solenoid)
- Fieldbus Nodes: FND-400 series (PROFIBUS/DeviceNet)
- Accessories: APV10 pressure sensors, AMH10 manual overrides
| Property | Property Value |
|---|---|
| sku | 7V100M4F |
