Airtac 7V-F Solenoid Valve Manifold 7V100M5F
2、Centralized air inlet/exhaust ports and integrated wiring simplify troubleshooting during maintenance:
3、Flexible modular configuration with expandable design - Allows arbitrary combination and expansion of connected directional control valves quantity;
Category: Solenoid Valve Bases , Brand: AirTAC , Series: 7V-F
AirTAC 7V-F Series Manifold Base 7V100M5F Technical Details
- Model: 7V100M5F
- Type: Modular manifold base for 5-station valve assembly
- Port configuration: 1/4" NPT (M5 threaded optional)
- Max operating pressure: 1.0 MPa
- Material: Reinforced PA66 + Glass fiber (30%)
- Seal compatibility: Compatible with NBR, FKM, or EPDM seals
- Weight: 480g ±5%
- Dimensions: 132mm(L) × 38mm(W) × 30mm(H)
- Port-to-port spacing: 18mm (ISO 4400 standard)
- Temperature resistance: -20℃ to 80℃ (with NBR seals)
- Pressure drop: ≤0.02 MPa at 700NL/min flow
- Mounting torque: 1.5-2.0 N·m (M5 screws)
- Certification: RoHS compliant, ISO 15407-1 standard
Multi-channel pneumatic distribution block engineered for high-density valve clustering in compact automation systems. Features precision-molded flow channels with optimized cross-section to minimize pressure loss. The anodized aluminum end plates provide EMI shielding and structural rigidity, while the modular design allows daisy-chaining up to 16 units.
- Multi-axis pneumatic actuator control in CNC machinery
- Automated production line sequencing valves
- Robotic end-effector tool changers
- Plastic injection molding machine air circuits
- Semiconductor wafer handling equipment
Installation protocol:
Align manifold base with DIN rail (35mm width) using TS-32 clips.
Apply thread sealant on NPT ports (tapered threads only).
Torque M5 mounting screws in diagonal sequence to 1.8N·m ±10%.
Perform pressure decay test at 0.6MPa before commissioning.
| Property | Property Value |
|---|---|
| sku | 7V100M5F |
