Airtac 7V-F Solenoid Valve Manifold 7V100M6F
2、Centralized air inlet/exhaust ports and integrated wiring simplify troubleshooting during maintenance:
3、Flexible modular configuration with expandable design - Allows arbitrary combination and expansion of connected directional control valves quantity;
Category: Solenoid Valve Bases , Brand: AirTAC , Series: 7V-F
AirTAC 7V-F Series Valve Manifold Base 7V100M6F Technical Details
- Model Code: 7V100M6F
- Type: Modular DIN rail manifold base
- Port configuration: 6 stations (supports multi-valve stacking)
- Port thread: G1/8 (ISO228 standard)
- Material: Reinforced PA66+30%GF (UL94 V-0 flame retardant)
- Max operating pressure: 1.0 MPa
- Proof pressure: 1.5 MPa
- Temperature range: -5℃ to 60℃ (with NBR seals)
- Seal compatibility: Works with NBR/FKM seals (specify when ordering)
- Weight: 220g ±5%
- Dimensions: 145mm(L) × 34mm(W) × 42mm(H) per station block
- Mounting: DIN rail (EN50022-35×7.5) or direct screw mounting
- Port alignment: 25mm center spacing between valves
- Air flow capacity: 750 Nl/min (at 0.5 MPa)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Multi-channel pneumatic distribution base designed for creating compact valve clusters in centralized control systems. Features dual O-ring sealing grooves for leak-proof connections and numbered station indicators for simplified maintenance. The anodized aluminum end plates provide structural rigidity, while the staggered port design prevents tool interference during manifold assembly.
- Modular production line actuator control panels
- Automated packaging machine air circuit distribution
- Robotic arm tool changer pneumatic systems
- Semiconductor manufacturing cleanroom equipment
- Plastic injection molding machine core pull circuits
Installation protocol:
Use torque-limited screwdriver (0.7-1.2Nm) for valve mounting.
Apply silicone-free lubricant to sealing surfaces before assembly.
Maintain 50mm clearance below base for tubing routing.
- 7V-F series solenoid valves (7V210, 7V220 variants)
- 7V-QS series quick-connect fittings
- 7V-EP electronic pilot valves
- ISO15407-2 compliant valve bodies
| Property | Property Value |
|---|---|
| sku | 7V100M6F |
