Airtac 7V Solenoid Valve 7V0510J04F200
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0510J04F200 Solenoid Valve Specifications
- Model: 7V0510J04F200
- Type: 5-port 2-position (5/2-way) solenoid valve with spring return
- Port size: PT1/4 (G1/4 optional)
- Effective sectional area: 17.5 mm²
- Operating pressure range: 0.1–1.0 MPa
- Max operating frequency: 5 Hz
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 3.5W / AC: 4.5VA
- Weight: 480g ±2%
- Dimensions: 59mm(W) × 38mm(H) × 125mm(L)
- Seal material: Heat-resistant NBR (Nitrile) up to 80℃
- Temperature range: -5℃ to 80℃ (with silicone seals: -20℃ to 70℃)
- Protection rating: IP67 (dustproof and waterproof immersion up to 1m)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Port thread depth: 12mm (minimum engagement)
High-flow 5/2-way valve featuring dual-pressure operation capability and manual override. Precision-machined aluminum body with anodized finish resists chemical corrosion. Optimized coil design reduces heat generation by 25% compared to previous generation models. Requires 5μm filtered dry air (ISO 8573-1:2010 Class 3.4.2).
- Double-acting cylinder control in automated assembly lines
- High-speed sorting/packaging machinery
- Plastic injection molding machine actuators
- Robotic welding station clamp controls
- Beverage filling system pneumatic circuits
Installation guidelines: Mount in vibration-free locations using M5 mounting screws (max torque 1.2N·m).
Maintain 20mm clearance around exhaust ports for proper venting. Lubricate seals with ISO VG32-grade
pneumatic oil if used in high-cycle applications (>1 million operations/year).
| Property | Property Value |
|---|---|
| sku | 7V0510J04F200 |
| Port Size | PT 1/2 |
| Standard Voltage | DC12V |
