Airtac 7V Solenoid Valve 7V0510M5F050
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0510M5F050 Solenoid Valve Technical Details
- Model Code: 7V0510M5F050 (Decoded: 7V Series | 05 Port Size | 10mm Orifice | M5 Coil | F Connector Type | 050 Special Option)
- Valve Type: 5/2-way monostable (single solenoid)
- Port Thread: G1/8 (ISO228 standard) with NPT1/8 adapter option
- Operating Pressure Range: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage Variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil Insulation: Class F (155℃ thermal rating)
- Flow Capacity: 750 l/min (ANR) at 0.5 MPa
- Response Time: ≤15ms (energize), ≤20ms (de-energize)
- Seal Materials: HNBR main seals + FKM secondary wipers
- Ambient Temperature: -5℃ to 60℃ (anti-condensation heater optional)
- Weight: 210g ±5g (excluding accessories)
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H) (manifold mounting surface included)
- Protection Class: IP67 (coil) / IP40 (valve body)
- Manual Override: Built-in push-button with lockable rotation
- Electrical Connection: DIN43650 Form A (direct lead wire optional)
High-flow 5/2 pneumatic valve with optimized spool geometry for reduced pressure drop. Features copper-free aluminum alloy body with hard anodizing, compatible with ISO 8573-1:2010 [3:4:3] compressed air quality. The M5 series coil incorporates surge protection and LED status indication. Designed for 1 million+ cycles at rated load.
- Pneumatic cylinder sequencing in assembly robots
- Dual-pressure control in plastic injection molding
- Vacuum/pressure switching in packaging lines
- Tool clamping systems for CNC machinery
- Actuator control in cleanroom environments
Installation Guidelines:1. Use ISO 16031 compliant piping seals
2. Maintain ≥85% rated voltage during operation
3. For horizontal mounting, install exhaust silencers vertically downward
4. Lubrication: ISO VG32 turbine oil recommended for high-cycle applications
| Property | Property Value |
|---|---|
| sku | 7V0510M5F050 |
| Port Size | M5 |
| Standard Voltage | DC12V |
