Airtac 7V Solenoid Valve 7V0510M5F200
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0510M5F200 Solenoid Valve Technical Profile
- Model Identification: 7V0510M5F200
- Valve Configuration: 5-port/3-position (center closed)
- Port Thread Standard: M5 × 0.8 (G1/8 equivalent flow)
- Pressure Operating Range: 0.1–0.7 MPa (14.5–101.5 PSI)
- Voltage Variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil Insulation Class: Class F (155°C)
- Flow Capacity (CV Value): 0.17 (at 0.5 MPa)
- Seal Material Options: NBR (standard), FKM (optional for high temp)
- Ambient Temperature Range: -5℃ to 60℃ (with NBR seals)
- Response Time: ≤30ms (energize), ≤50ms (de-energize)
- Protection Rating: IP67 (dustproof & temporary immersion)
- Weight: 280g ±5g (with coil)
- Body Dimensions: 55mm(W) × 45mm(H) × 63mm(D)
- Mounting Orientation: Any (universal installation)
- Manual Override: Built-in emergency switch
High-performance 5/3-way pneumatic solenoid valve featuring a center-block design for mid-position cylinder control. The aluminum alloy body with hard anodized treatment ensures corrosion resistance in humid environments. Unique "F" series coil provides 30% higher pull force than standard models, maintaining stable operation even with pressure fluctuations.
- Pneumatic cylinder sequencing in assembly line automation
- Vacuum generator control in packaging machinery
- Bi-directional actuator control for robotic arms
- Central lubrication system switching in CNC equipment
- Air circuit selection in cleanroom automation
Installation Protocol:
Always install optional silencer (AS-01M) when used in food-grade applications.
Maintain minimum 50mm clearance below valve for condensate drainage.
Use copper-free anti-seize compound on threads for stainless steel piping.
| Property | Property Value |
|---|---|
| sku | 7V0510M5F200 |
| Port Size | M5 |
| Standard Voltage | DC12V |
