Airtac 7V Solenoid Valve 7V0520J04A200
Genuine AirTAC solenoid valve, order code 7V0520J04A200 from the 7V0520 range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- PortØ4 mm push-in (J04)
- Coil voltageAC220V (A)
- Lead wireLead 2.0 m (200)
- Function5/2-way double solenoid (double solenoid with memory)
- PortsM5, Ø4 mm push-in (J04)
- Effective area3.4 mm² (Cv 0.2) on M5
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 7V Solenoid Valve 7V0520J04A200
With an AC220V coil and a 2.0 m lead, the AirTAC 7V0520J04A200 is a 5/2-way double-solenoid valve with Dia 4 mm push-in A and B ports. A pulse on either coil shifts the spool and it stays there until the other coil is pulsed, so it keeps its position through a power cut. The push-in version has oval bottom ports and is used only on a 7V0500M manifold base, which supplies P and the exhausts. The catalog flow on M5 is 3.4 mm2 (Cv 0.2), measured on the threaded version. The AC220V coil (code A) draws 1.1 VA, is class F and dust-protected, responds in 0.05 s or less and plugs in horizontally or vertically; the 200 code gives a 2.0 m lead.
It is pilot operated from 0.15 to 0.8 MPa (21-114 psi) on air filtered to 40 um, proof pressure 1.2 MPa, -10 to +50 C, at up to 5 cycles/s, and weighs 45 g. The die-cast aluminum-alloy body collects the pilot exhaust and vents it through the R and S ports. No lubrication is needed; once lubricated air is used, keep using it with ISO VG32 oil.
Airtac 7V Solenoid Valve 7V0520J04A200 Technical Specifications
| Order code | 7V0520J04A200 |
|---|---|
| Product | Solenoid Valve |
| Port | Ø4 mm push-in (J04) |
| Coil voltage | AC220V (A) |
| Lead wire | Lead 2.0 m (200) |
| Function | 5/2-way double solenoid (double solenoid with memory) |
|---|---|
| Ports | M5, Ø4 mm push-in (J04) |
| Effective area | 3.4 mm² (Cv 0.2) on M5 |
| Weight | 45 g |
| Max frequency | 5 cycles/s |
| Fluid | Air (filtered by 40 µm element) |
| Pilot | Internal |
| Operating pressure | 0.15 – 0.8 MPa (21 – 114 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -10 to +50 °C |
| Coil power | AC 1.1 VA · DC 0.7 W |
| Voltage tolerance | AC +15% / -10%, DC ±10% |
| Insulation | Class F, dust-protected |
| Body | Aluminum alloy |
| Lubrication | Not required |
Source: AirTAC catalog P80, 7V series specifications and ordering code. Effective area is the catalog figure for the M5 port.
How to choose
Within the 7V0520, DC24V, AC110V and DC12V coils replace the A with B/C/F; 7V0520J04A050 has the 0.5 m lead; the other ports of this body are M5 (7V0520M5A200). The same body comes as 7V0510, 7V0530C, 7V0530E and 7V0530P: 10 single solenoid, 20 double solenoid, 30C/30E/30P the 5/3-way centers. Several 7V0500 valves can share a 7V0500M manifold base of 1 to 20 stations.
Applications
Holds position on power loss
A pulse from a 220 V AC control panel switches the cylinder and the valve keeps that position until the other coil is pulsed.
Manifold valve banks
The Dia 4 mm push-in A and B ports take tubes straight on the valve while the 7V0500M base carries supply and exhaust.
AC220V control circuits
The AC220V coil connects to a 220 V AC control panel; the 2.0 m lead plugs into the coil terminal.
FAQ
What are the key figures of the 7V0520J04A200?
5/2-way double-solenoid valve, 7V0500 series; Dia 4 mm push-in ports; catalog flow 3.4 mm2 (Cv 0.2); 0.15-0.8 MPa (21-114 psi), proof 1.2 MPa; -10 to +50 C; up to 5 cycles/s; AC220V coil, 1.1 VA, class F; 2.0 m lead; response 0.05 s or less; 45 g.
Can the 7V0520J04A200 be piped on its own?
No. The push-in version has only the A and B ports on the valve; it mounts on a 7V0500M manifold base, which provides the supply and exhaust.
