Airtac 7V Solenoid Valve 7V0520J04C050
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0520J04C050 Solenoid Valve Specifications
- Model: 7V0520J04C050
- Type: 5/2-way single solenoid spring return (direct-acting)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 280g ±5% (without connector)
- Dimensions: 56mm(L) × 38mm(W) × 72mm(H)
- Seal material: Temperature-resistant NBR (Nitrile) standard, FKM (Viton) optional
- Temperature range: -5℃ to 80℃ (non-freezing conditions)
- Power consumption: DC: 2.8W max | AC: 3.5VA max
- Protection rating: IP67 (dustproof & waterproof)
- Response time: ≤15ms (at 0.5MPa)
- Flow capacity: 750 l/min (Cv=1.2)
- Port thread depth: 12mm (minimum engagement)
High-speed 5-port pneumatic valve with double-seal structure for leak prevention. Features anti-vibration design (up to 10Hz/1.5mm amplitude) and manual override button. Optimized for frequent switching cycles (≥30 million operations). Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Multi-axis pneumatic cylinder control systems
- Automated assembly line tooling changers
- Textile machinery shuttle control
- Bottle cap screwing/unscrewing machines
- Semiconductor wafer handling robots
Installation protocol:
Mount using M4 screws with 0.6-0.8Nm torque. Maintain ≥20mm clearance
below valve for connector access. Use flexible tubing to prevent
mechanical stress. Perform monthly exhaust port cleaning in dusty environments.
Critical note:
Avoid continuous energization >60 minutes. For vertical mounting,
ensure solenoid orientation follows arrow marking to prevent
magnetic particle accumulation.
| Property | Property Value |
|---|---|
| sku | 7V0520J04C050 |
| Port Size | PT 1/2 |
| Standard Voltage | AC 110V |
