Airtac 7V Solenoid Valve 7V0520J04F050
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0520J04F050 Solenoid Valve Technical Specifications
- Model: 7V0520J04F050
- Type: 5/2-way monostable (pilot-operated)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Power consumption: 1.8W (DC), 4.5VA (AC)
- Flow capacity: Cv=1.8 / Kv=2.08 (at 7 bar)
- Seal material: NBR (standard), optional Viton for high temp (up to 120℃)
- Ambient temperature: -5℃ to 60℃ (with NBR seals)
- Response time: ≤20ms (at rated voltage)
- Weight: 320g ±5% (with coil)
- Dimensions: 58mm(L) × 42mm(W) × 78mm(H) (excluding connectors)
- Port thread depth: 12mm (minimum engagement 9mm)
- Protection rating: IP67 (coil), IP40 (valve body)
- Service life: ≥10 million cycles (under standard conditions)
High-flow proportional control valve with manual override capability, featuring brass main body and chrome-plated spool for enhanced durability. The 7V0520J04F050 employs dual-pressure operation with improved pilot structure for stable performance in vibration-prone environments. Requires 5μm filtered air with lubrication (ISO 8573-1 class 4) and oil mist lubrication recommended.
- Automated production line clamping/unclamping systems
- Plastic injection molding machine ejectors
- CNC tool changers with rapid cycle requirements
- Paper processing equipment with sequential valve arrangements
- Bottle filling systems requiring bi-directional actuation
Installation guidelines:
Mount with 10mm clearance around valve body for heat dissipation.
Use flexible tubing to isolate vibration. Lubricate every 3 months
under continuous operation. Maximum allowable mounting angle: 15°
from vertical axis.
- Speed controller: AS2201F-04
- Quick connector: QSML-4-M5
- Mounting bracket: VB-15 series
| Property | Property Value |
|---|---|
| sku | 7V0520J04F050 |
| Port Size | PT 1/2 |
| Standard Voltage | DC12V |
