Airtac 7V Solenoid Valve 7V0520M5B050
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0520M5B050 Solenoid Valve Technical Profile
- Full model designation: 7V0520M5B050
- Valve type: 5/2-way monostable (single solenoid)
- Port configuration: M5 threaded (ISO 228 standard)
- Effective section area: 0.52mm²
- Operating pressure range: 0.15–0.7 MPa (21.7–101.5 PSI)
- Proof pressure: 1.05 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%)
- Coil insulation class: Class F (155℃)
- Power consumption: 1.6W (DC24V) / 3.2W (DC12V)
- Response time: ≤15ms (excitation), ≤20ms (de-energization)
- Seal material: Fluorocarbon rubber (FKM)
- Ambient temperature: -5℃ to 60℃ (no freezing)
- Fluid temperature: 0–60℃
- Protection class: IP67 (dust tight & protected against immersion)
- Manual override: Built-in emergency actuation button
- Weight: 220g ±5g (including coil)
- Dimensions: 58mm(L) × 34mm(W) × 45mm(H)
High-density 5-port directional control valve optimized for multi-actuator systems requiring sequential operations. Features corrosion-resistant aluminum alloy body with hard anodized treatment. The M5B coil assembly incorporates overvoltage protection and surge suppression diodes. Requires ISO 8573-1:2010 Class 3 compressed air (max particle size 5μm, oil content ≤1mg/m³).
- Multi-axis pneumatic gripper coordination in assembly robots
- Pneumatic indexing tables with position sequencing
- Textile machinery cylinder control systems
- Semiconductor wafer handling equipment
- Automated liquid dispensing systems with dual actuators
Maintenance protocol:
Lubricate spool every 5 million cycles using ISO VG32 turbine oil.
Avoid axial mounting - lateral installation reduces particulate
accumulation in pilot channels. Minimum 12VDC required for stable
operation below 0.3MPa.
| Property | Property Value |
|---|---|
| sku | 7V0520M5B050 |
| Port Size | M5 |
| Standard Voltage | DC24V |
