Airtac 7V Solenoid Valve 7V0520M5C050
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0520M5C050 Solenoid Valve Technical Details
- Model: 7V0520M5C050 (7V Series Direct-Acting)
- Valve type: 5/2-way monostable, double solenoid (optional single coil)
- Port configuration: M5 threaded ports (5 ports, 2 positions)
- Effective area ratio: 1:1.2 (pilot to main valve)
- Operating pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Power consumption: DC: 2.5W max / AC: 3.5VA max
- Flow capacity: CV=0.18 (Kv=0.16) @ 0.5MPa
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Ambient temperature: -5℃ to 60℃ (no freeze)
- Seal material: NBR (standard), optional FKM for high temp (max 80℃)
- Weight: 230g ±5g (with coils)
- Dimensions: 55mm(L) × 34mm(W) × 68mm(H)
- Protection class: IP67 (dust/water resistant)
- Port thread depth: 8mm (minimum engagement)
High-speed 5/2-way valve optimized for precision pneumatic sequencing in compact installations. Features zero pressure start capability and low hysteresis design for repetitive motion control. Requires 5μm filtered lubricated air (ISO 8573-1 class 4). Includes manual override and LED status indicator (selectable models).
- Pick-and-place robot end effectors
- Textile machinery shuttle controls
- Semiconductor wafer handling systems
- Bottle capping machine actuators
- High-cycle packaging cylinder drives
Installation protocol:
Mount with vibration-damping brackets in high-G environments.
Maintain ≥15mm lateral clearance for heat dissipation.
Use Loctite 243 on thread ports (non-permanent).
Cycle test 3x before full operation.
| Property | Property Value |
|---|---|
| sku | 7V0520M5C050 |
| Port Size | M5 |
| Standard Voltage | AC 110V |
