Airtac ACE Compact Cylinder ACE100X100B
The AirTAC Airtac ACE Compact Cylinder ACE100X100B is a genuine double acting ISO 21287 compact air cylinder with a Ø100mm bore and 100mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke100 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACE Compact Cylinder ACE100X100B
This AirTAC ACE100X100B is a double acting compact cylinder that extends and retracts its 20 mm rod with air on both strokes. It delivers a 3927 N push and a 3769.9 N pull at 0.5 MPa, so it suits heavy clamping and pressing tasks in a short envelope.
The ISO 21287 body is about 50% shorter than an ISO 15552 profile cylinder, freeing space in tight fixtures. The male rod thread (B code) simplifies direct coupling, and the 1/4" port accepts standard fittings. For a safe working load, plan on roughly 2356 N at 0.5 MPa, which equals about 240 kg of vertical lift with a 2:1 margin.
Airtac ACE Compact Cylinder ACE100X100B Technical Specifications
| Model | Airtac ACE Compact Cylinder ACE100X100B |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3770 N |
| 0.7 MPa | 5498 N | 5278 N |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACE Compact Cylinder ACE100X100B
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACE Compact Cylinder ACE100X100B Is Used
Heavy Clamp Fixture
Use in a CNC machining fixture to clamp thick steel plates with a 3927 N force at 0.5 MPa, holding parts securely during milling.
Carton Compression Test
Drive a platen to compress corrugated cartons in a quality lab, applying a controlled 3769.9 N pull to test stacking strength.
Press Ram for Assembly
Press bushings into aluminum housings on an assembly line, using the 5497.8 N push at 0.7 MPa for reliable insertion.
Is the Airtac ACE Compact Cylinder ACE100X100B the Right Cylinder?
For lighter duty, the ACE80X100 offers a 2513.3 N push at 0.5 MPa, while the ACE125X100 provides a 6135.9 N push for heavier work. This 100 mm bore model fits applications needing a strong push without the bulk of a larger cylinder. Since the B code specifies a male rod thread, verify your coupling matches M12x1.75. The optional -S magnet is not fitted, so sensor mounting requires ordering that code separately.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACE Compact Cylinder ACE100X100B FAQ
At 0.5 MPa, push is 3927 N and pull is 3769.9 N. At 0.7 MPa, push is 5497.8 N and pull is 5277.9 N. The theoretical maximum force is 800.9 kgf at 1.0 MPa.
The short body saves about 50% of the mounting length compared to an ISO 15552 profile cylinder, so it fits inside machine guards and compact jigs. The fixed TPU bumper absorbs end-of-stroke energy, and the hard-anodized aluminum body resists wear.
