Airtac ACE Compact Cylinder ACE100X10B
The AirTAC Airtac ACE Compact Cylinder ACE100X10B is a genuine double acting ISO 21287 compact air cylinder with a Ø100mm bore and 10mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke10 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACE Compact Cylinder ACE100X10B
This AirTAC ACE100X10B is a double acting compact cylinder built to ISO 21287, with a 100 mm bore and a 10 mm stroke. Its hard-anodized aluminium body is about 50% shorter than an ISO 15552 profile cylinder, so it fits into tight machine frames and guarding where a full-length actuator will not.
At 0.5 MPa this unit pushes with 3927 N and pulls with 3769.9 N, so it can drive heavy clamping or pressing actions in a compact envelope. For a real-world guide, plan on about 240 kg of safe vertical lifting at 0.5 MPa when you apply a 2:1 margin, and remember this is a fixed TPU bumper design, not an adjustable air cushion. The male rod thread (B code) lets you bolt on custom tooling directly.
Airtac ACE Compact Cylinder ACE100X10B Technical Specifications
| Model | Airtac ACE Compact Cylinder ACE100X10B |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3770 N |
| 0.7 MPa | 5498 N | 5278 N |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACE Compact Cylinder ACE100X10B
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 100 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACE Compact Cylinder ACE100X10B Is Used
Die Stamping Press
Use the 3927 N push at 0.5 MPa to drive a small stamping die in a compact press frame, where the short ISO 21287 body saves valuable vertical space.
Conveyor Stop Gate
Mount this cylinder to raise a stop gate on a packaging line. The 10 mm stroke is enough to block or release cartons, and the male rod thread simplifies attaching a custom paddle.
Clamping Fixture
In a CNC workholding fixture, the ACE100X10B delivers strong clamping force with a short stroke, letting you secure large parts without a bulky cylinder protruding from the fixture.
Is the Airtac ACE Compact Cylinder ACE100X10B the Right Cylinder?
Choose the ACE100X10B when you need a high-force, short-stroke actuator for a confined space. For lighter work, the ACE80X10 offers 2513.3 N push at 0.5 MPa, while the ACE125X10 steps up to 6135.9 N push at 0.5 MPa if you need more muscle. This model has no magnet, so it cannot be used with CMSE or DMSE sensors unless you order the optional -S version.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACE Compact Cylinder ACE100X10B FAQ
At 0.5 MPa, push is 3927 N and pull is 3769.9 N. At 0.7 MPa, push is 5497.8 N and pull is 5277.9 N. The theoretical maximum force is 800.9 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa (22-145 psi), with proof pressure at 1.5 MPa (215 psi).
No. The ACE100X10B is a double acting cylinder with a fixed TPU bumper at both ends, but the bumper only absorbs end-of-stroke impact. It does not lock or hold a load in position. If you need to hold a load when air is lost, use an external rod lock or a pilot check valve.
