Airtac ACE Compact Cylinder ACE100X110S
The AirTAC Airtac ACE Compact Cylinder ACE100X110S is a genuine double acting ISO 21287 compact air cylinder with a Ø100mm bore and 110mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke110 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACE Compact Cylinder ACE100X110S
This AirTAC ACE100X110S is a double acting ISO 21287 compact cylinder with a 100 mm bore and a 110 mm stroke, delivering a 3927 N push force at 0.5 MPa. Its hard-anodized aluminium body and S45C hard-chrome plated rod are built for repetitive automation duty, and a fixed TPU bumper at each end absorbs impact energy.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it fits into tight machine frames and guarding where a full-length cylinder will not. With the optional -S magnet fitted, this unit works with CMSE or DMSE reed and solid-state switches for position sensing. As a buyer rule, plan for about 240 kg of real vertical work at 0.5 MPa, not the full 3927 N rating, to keep a safety margin.
Airtac ACE Compact Cylinder ACE100X110S Technical Specifications
| Model | Airtac ACE Compact Cylinder ACE100X110S |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 110 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3770 N |
| 0.7 MPa | 5498 N | 5278 N |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACE Compact Cylinder ACE100X110S
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 100 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACE Compact Cylinder ACE100X110S Is Used
Jig Clamping
Clamp large sheet-metal panels in a welding fixture with the 3927 N push force at 0.5 MPa, using the compact body to fit between locating pins.
Conveyor Stop Gate
Raise a 240 kg stop gate on a packaging line at 0.5 MPa, with the 110 mm stroke providing enough lift to clear product flow.
Press Ram Feed
Push a die slide into a small press with the 5498 N push at 0.7 MPa, using the magnet to confirm full extension via a CMSE switch.
Is the Airtac ACE Compact Cylinder ACE100X110S the Right Cylinder?
For a lighter duty on the same 110 mm stroke, the ACE80X110S offers a 2513 N push at 0.5 MPa, while stepping up to the ACE125X110S gives 6136 N push for heavier loads. This ACE100X110S suits medium-to-heavy clamping, pressing, or lifting tasks where the 3927 N push and 3770 N pull at 0.5 MPa are needed.
Since this model carries the -S magnet, you can mount CMSE or DMSE switches directly to sense the rod position. The 1/4" port and M12x1.75 female rod thread match standard fittings. Remember that a plain ACE does not hold its load when air is removed; use a rod lock or pilot check valve for position holding.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACE Compact Cylinder ACE100X110S FAQ
At 0.5 MPa, push is 3927 N and pull is 3769.9 N. At 0.7 MPa, push is 5497.8 N and pull is 5277.9 N. The theoretical maximum force is 800.9 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa (22-145 psi).
The ACE100X110S body is about 50% shorter than an ISO 15552 profile cylinder of the same stroke, so it fits inside machine guards and between frame members. The fixed TPU bumper absorbs end-of-stroke energy, and the -S magnet allows CMSE or DMSE switch mounting for position feedback.
