Airtac ACE Compact Cylinder ACE100X120SB
The AirTAC Airtac ACE Compact Cylinder ACE100X120SB is a genuine double acting ISO 21287 compact air cylinder with a Ø100mm bore and 120mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke120 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACE Compact Cylinder ACE100X120SB
This AirTAC ACE100X120SB is a double acting compact cylinder that delivers a robust 3927 N push force at 0.5 MPa, making it suitable for demanding automation tasks. Its ISO 21287 short body is about 50% shorter than an ISO 15552 profile cylinder, allowing it to fit into tight machine frames and guarding where space is at a premium.
With the optional -S magnet fitted, this model is ready for CMSE or DMSE reed and solid-state switches, enabling reliable position sensing. The hard-anodized aluminium body and S45C hard-chrome plated rod ensure long service life, while the fixed TPU bumper at both ends absorbs end-of-stroke impacts. For a 2:1 safety margin on vertical lifts, plan for about 200 kg of real work at 0.5 MPa, not the full 3927 N rating.
Airtac ACE Compact Cylinder ACE100X120SB Technical Specifications
| Model | Airtac ACE Compact Cylinder ACE100X120SB |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 120 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3770 N |
| 0.7 MPa | 5498 N | 5278 N |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACE Compact Cylinder ACE100X120SB
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 100 | Bore size in mm. |
| ×120 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACE Compact Cylinder ACE100X120SB Is Used
Assembly Press
Use in a benchtop press for pressing bearings into housings, where the 3927 N push force and compact body fit under a guard.
Package Stop Gate
Mount on a conveyor line to raise and lower a stop gate for diverting boxes, using the 120 mm stroke and reliable retraction.
Clamping Fixture
In a CNC machining fixture, clamp parts with 3927 N force; the short profile leaves room for tooling and chip clearance.
Is the Airtac ACE Compact Cylinder ACE100X120SB the Right Cylinder?
For lighter duty, consider the ACE80X120 with a 2513 N push at 0.5 MPa, or step up to the ACE125X120 for a 6135.9 N push. The male rod thread (B code) simplifies mounting with rod-end accessories, and the 1/4" port ensures adequate flow for this bore size. Remember, this cylinder does not hold its position if air pressure is lost; use a rod lock or pilot check valve for load holding.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACE Compact Cylinder ACE100X120SB FAQ
At 0.5 MPa, push force is 3927 N and pull force is 3769.9 N. At 0.7 MPa, push is 5497.8 N and pull is 5277.9 N. The theoretical maximum force is 800.9 kgf at 1.0 MPa.
The magnet is an optional -S feature, and this model includes it. With the magnet, you can mount CMSE or DMSE reed or solid-state switches for position sensing. Without the -S code, no magnet is present.
