Airtac ACE Compact Cylinder ACE100X125SBFTC
The AirTAC Airtac ACE Compact Cylinder ACE100X125SBFTC is a genuine double acting ISO 21287 compact air cylinder with a Ø100mm bore and 125mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke125 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACE Compact Cylinder ACE100X125SBFTC
This AirTAC ACE100X125SBFTC is a double acting ISO 21287 compact cylinder delivering 3927 N of push force at 0.5 MPa. Its short body saves about 50% of the mounting length compared to an ISO 15552 profile cylinder, making it ideal for tight automation cells. The optional -S magnet is fitted here, so CMSE or DMSE reed and solid-state switches can be mounted for position sensing.
The 100 mm bore with a 125 mm stroke uses a hard-anodized aluminium body and an S45C carbon-steel rod with hard-chrome plating. At 0.5 MPa, the pull force is 3769.9 N, and at 0.7 MPa push rises to 5497.8 N. For a safe working load, plan around 2356 N (about 240 kg) at 0.5 MPa to keep a 2:1 margin for real applications.
Airtac ACE Compact Cylinder ACE100X125SBFTC Technical Specifications
| Model | Airtac ACE Compact Cylinder ACE100X125SBFTC |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 125 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3770 N |
| 0.7 MPa | 5498 N | 5278 N |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACE Compact Cylinder ACE100X125SBFTC
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 100 | Bore size in mm. |
| ×125 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACE Compact Cylinder ACE100X125SBFTC Is Used
Assembly Press
Use in a benchtop press for inserting bearings into housings, where 3927 N at 0.5 MPa provides the force to seat parts consistently.
Conveyor Stop Gate
Mount with FTC bracket to a conveyor frame to raise and lower a stop gate, handling 125 mm stroke to control product flow on a packaging line.
Clamping Fixture
In a CNC machining fixture, this cylinder clamps a 100 mm workpiece with 3927 N, holding it securely during drilling operations.
Is the Airtac ACE Compact Cylinder ACE100X125SBFTC the Right Cylinder?
For lighter duty, consider the ACE80X125 with 2513.3 N push at 0.5 MPa, or step up to the ACE125X125 for 6135.9 N push. This model's 1/4" port suits standard shop air, and the FTC mounting bracket provides a rigid fixed mount. The male rod thread (B code) simplifies attachment of custom tooling, and the fitted magnet allows easy sensor integration.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACE Compact Cylinder ACE100X125SBFTC FAQ
At 0.5 MPa, push is 3927 N and pull is 3769.9 N. At 0.7 MPa, push is 5497.8 N and pull is 5277.9 N. The theoretical maximum force is 800.9 kgf at 1.0 MPa. Operating pressure range is 0.15-1.0 MPa (22-145 psi).
The short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it fits into tight spaces like guard enclosures or gantries. The fixed TPU bumper at both ends absorbs end-of-stroke impact, and the optional -S magnet (fitted here) allows CMSE or DMSE switches for position sensing.
