Airtac ACE Compact Cylinder ACE100X15
The AirTAC Airtac ACE Compact Cylinder ACE100X15 is a genuine double acting ISO 21287 compact air cylinder with a Ø100mm bore and 15mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke15 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACE Compact Cylinder ACE100X15
This AirTAC ACE100X15 is a double acting compact cylinder that delivers 3927 N of push force at 0.5 MPa, making it a strong choice for medium-duty automation. The 100 mm bore with a 15 mm stroke fits where a longer ISO 15552 profile cylinder would not, since the ISO 21287 body saves about 50% of the mounting length.
With a pull force of 3769.9 N at 0.5 MPa, this cylinder can handle retraction loads nearly as heavy as its extension. For a safe working load, plan for about 240 kg of real work at 0.5 MPa, which is roughly 0.6 times the push force, so you can match it to a specific part weight without over-specifying.
Airtac ACE Compact Cylinder ACE100X15 Technical Specifications
| Model | Airtac ACE Compact Cylinder ACE100X15 |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 15 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3770 N |
| 0.7 MPa | 5498 N | 5278 N |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACE Compact Cylinder ACE100X15
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 100 | Bore size in mm. |
| ×15 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACE Compact Cylinder ACE100X15 Is Used
Fixture Clamping
Use the 3927 N push force to clamp sheet metal parts in a welding jig, where the short 15 mm stroke keeps the fixture compact and the 1/4" port allows quick air supply.
Carton Ejection
In a packaging line, this cylinder can push filled cartons off a conveyor onto a chute, with the 3769.9 N pull retracting the rod fast enough for cycle rates up to 500 mm/s.
Press Ram
For a small press operation, the 5497.8 N push at 0.7 MPa can stamp or emboss labels onto plastic parts, while the fixed TPU bumper absorbs the end-of-stroke impact without shock.
Is the Airtac ACE Compact Cylinder ACE100X15 the Right Cylinder?
When sizing, compare this 100 mm bore to the 125 mm bore which pushes 6135.9 N at 0.5 MPa, or drop to the 80 mm bore at 2513.3 N if your load is lighter. The 15 mm stroke is well under the 300 mm maximum standard stroke for this bore, so it is a standard off-the-shelf unit. Since this model has no -S magnet, it cannot accept CMSE or DMSE sensors; order the optional -S code if you need position sensing. Mounting options include FA/FB flange, LB foot, CA/CB clevis, CR, SDB pivot, and FTC brackets, all compatible with the ISO 21287 face.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACE Compact Cylinder ACE100X15 FAQ
At 0.5 MPa, the push force is 3927 N and the pull force is 3769.9 N. At 0.7 MPa, push is 5497.8 N and pull is 5277.9 N. The theoretical maximum force is 800.9 kgf at 1.0 MPa. The operating pressure range is 0.15-1.0 MPa (22-145 psi), with a proof pressure of 1.5 MPa (215 psi).
The ACE100X15 has a hard-anodized aluminium body that is about 50% shorter than an ISO 15552 profile cylinder, so it fits into tight machine guards and gantries. It uses a fixed TPU bumper at both ends to absorb impact, and the rod is S45C carbon steel with hard-chrome plating. The optional -S magnet is not fitted here, so CMSE or DMSE sensors are only available if you order the -S version.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
Request a Quote for Airtac ACE Compact Cylinder ACE100X15
Send us the quantity and destination. We confirm price, stock and lead time — usually within 7-8 hours.
