Airtac ACE Compact Cylinder ACE100X150B
The AirTAC Airtac ACE Compact Cylinder ACE100X150B is a genuine double acting ISO 21287 compact air cylinder with a Ø100mm bore and 150mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke150 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACE Compact Cylinder ACE100X150B
The ACE100X150B is a double acting ISO 21287 compact cylinder with a 100 mm bore and 150 mm stroke, delivering a 3927 N push force at 0.5 MPa. Its hard-anodized aluminium body is about 50% shorter than an ISO 15552 profile cylinder, fitting into tight machine frames where full-length cylinders cannot go.
This model has a male rod thread (B code) and no magnet, so it cannot accept CMSE or DMSE sensors unless you order the optional -S version. For a 2:1 safety margin on vertical moves, plan to lift about 200 kg (3927 N divided by 9.81, then halved) rather than the full theoretical rating.
Airtac ACE Compact Cylinder ACE100X150B Technical Specifications
| Model | Airtac ACE Compact Cylinder ACE100X150B |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 150 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3770 N |
| 0.7 MPa | 5498 N | 5278 N |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACE Compact Cylinder ACE100X150B
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 100 | Bore size in mm. |
| ×150 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACE Compact Cylinder ACE100X150B Is Used
Jig Clamping
Clamp sheet-metal fixtures in a stamping press with 3927 N push force, using the compact body to fit under the die shoe where a profile cylinder would not clear.
Package Stop
Actuate a stop gate on a packaging conveyor, pushing against cartons with 3769 N pull force to retract the rod and clear the line at speeds up to 500 mm/s.
Part Ejection
Eject molded plastic parts from a die-cast machine with a 150 mm stroke, using the fixed TPU bumper to absorb end-of-stroke shock without damaging the part.
Is the Airtac ACE Compact Cylinder ACE100X150B the Right Cylinder?
For a lighter duty, the ACE80X150 has a 2513 N push at 0.5 MPa, while the ACE125X150 steps up to 6135 N push. Since this cylinder has no magnet, choose the -S code if you need position sensing; otherwise, use external limit switches. The male rod thread simplifies coupling to clevises or rod knuckles, and the 1/4" port suits standard shop air lines.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACE Compact Cylinder ACE100X150B FAQ
At 0.5 MPa, push is 3927 N and pull is 3769.9 N. At 0.7 MPa, push is 5497.8 N and pull is 5277.9 N. Theoretical maximum force is 800.9 kgf at 1.0 MPa. Operating pressure range is 0.15-1.0 MPa (22-145 psi), proof pressure is 1.5 MPa (215 psi).
Yes, it is an ISO 21287 compact cylinder with a body about 50% shorter than an ISO 15552 profile cylinder. It has a fixed TPU bumper at both ends, not an adjustable cushion. This version has no magnet, so CMSE or DMSE switches cannot be mounted unless you order the optional -S code.
