Airtac ACE Compact Cylinder ACE100X150SB
The AirTAC Airtac ACE Compact Cylinder ACE100X150SB is a genuine double acting ISO 21287 compact air cylinder with a Ø100mm bore and 150mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke150 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACE Compact Cylinder ACE100X150SB
This AirTAC ACE100X150SB is a double acting ISO 21287 compact cylinder with a 100 mm bore and 150 mm stroke, delivering 3927 N push and 3769.9 N pull at 0.5 MPa. Its hard-anodized aluminium body and S45C hard-chrome rod resist wear in demanding cycles, and the fixed TPU bumper absorbs end-of-stroke impact.
Because the body is about 50% shorter than an ISO 15552 profile cylinder, it fits inside tight machine guards and gantries where a full-length unit will not. The optional -S magnet is fitted here, so CMSE or DMSE reed and solid-state switches can mount directly to sense rod position. For a real workload, plan on roughly 240 kg of safe vertical lift at 0.5 MPa, using a 2:1 margin over the theoretical 3927 N push.
Airtac ACE Compact Cylinder ACE100X150SB Technical Specifications
| Model | Airtac ACE Compact Cylinder ACE100X150SB |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 150 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3770 N |
| 0.7 MPa | 5498 N | 5278 N |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACE Compact Cylinder ACE100X150SB
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 100 | Bore size in mm. |
| ×150 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACE Compact Cylinder ACE100X150SB Is Used
Fixture Clamping
Use the 3927 N push at 0.5 MPa to clamp sheet-metal panels in a CNC drilling fixture, where the short body fits between locating pins and the 150 mm stroke clears the part.
Carton Transfer
Mount on a packaging line to push 30 kg cartons sideways onto a transfer belt; the 3769.9 N pull retracts quickly at 0.5 MPa, and the fixed TPU bumper prevents shock at end of stroke.
Pallet Stops
Deploy as a pallet stop on an automated storage aisle, using the 5497.8 N push at 0.7 MPa to hold a loaded pallet in place, with the optional -S magnet signaling position to a PLC.
Is the Airtac ACE Compact Cylinder ACE100X150SB the Right Cylinder?
For lighter indexing tasks, the ACE80X150 with 2513.3 N push at 0.5 MPa saves space and air, while the ACE125X150 with 6135.9 N push handles heavier pallets. Since this model carries the -S magnet, order CMSE or DMSE switches for position sensing; without the -S code no magnet is present. The male rod thread (B) suits clevis or rod-end attachments, and FA/FB flange, LB foot, CA/CB clevis, CR, SDB pivot, and FTC brackets bolt to the ISO 21287 face. A plain ACE does not hold its load when air is lost, so add a rod lock or pilot check valve for vertical or drifting loads.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACE Compact Cylinder ACE100X150SB FAQ
At 0.5 MPa, push is 3927 N and pull is 3769.9 N. At 0.7 MPa, push rises to 5497.8 N and pull to 5277.9 N. The theoretical maximum force at 1.0 MPa is 800.9 kgf. These values are for the 100 mm bore with a 20 mm rod.
It follows ISO 21287, so its body is about 50% shorter than an ISO 15552 profile cylinder, saving space in tight machinery. The fixed TPU bumper at each end absorbs energy at stroke end, but it is not adjustable and does not lock or hold a load. For position sensing, the fitted -S magnet allows CMSE or DMSE switches to detect the rod position.
