Airtac ACKDL Rotary Type Cylinder ACKDL32X90
2. Triple-guide groove structure delivers high-precision alignment and directional stability;
3. Available in single-acting and double-acting (90°) operation configurations;
4. Flexible rotation options: left-hand/right-hand rotation with 90° and 180° rotation angles;
5. Heat-treated piston rod manufactured from special alloy steel guarantees enhanced durability and prolonged service life.
Category: Angular Rotation Cylinders | Brand: AirTAC | Series: ACKDL
AirTAC ACKDL32X90 Compact Rotary Actuator Specifications
- Model: ACKDL32X90 (90° rotation type)
- Bore size: 32mm
- Stroke: 90° rotation angle
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning type: Adjustable cushioning (both sides)
- Mounting style: 4×M5 threaded holes + dual shaft options
- Port size: G1/8 (ISO standard)
- Material: Aluminum alloy body, stainless steel piston rod
- Protection class: IP40 (dust protected)
- Weight: 1.45 kg ±2%
- Dimensions: 100mm(L) × 80mm(W) × 85mm(H)
- Torque output: 2.0 N·m @ 0.5 MPa
- Rotation accuracy: ±0.5°
- Lubrication: Pre-lubricated (use ISO VG32 hydraulic oil if maintenance required)
High-torque compact rotary actuator featuring twin-piston rack-and-pinion design for precise angular positioning. The dual-shaft configuration allows mechanical synchronization in complex mechanisms. Integrated magnetic ring enables position feedback when paired with sensors (optional).
- 90° part flipping in automated assembly lines
- Clamping fixture rotation in CNC machining centers
- Valve actuation in food processing equipment
- Pallet orientation adjustment in logistics systems
- Camera/Sensor positioning in inspection machinery
Installation guidelines:
Maintain 0.5-1mm clearance between actuator and mounting surface for thermal expansion.
Use Loctite 243 on mounting screws (M5×12 recommended). Avoid side-load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | ACKDL32X90 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | PT1/8 |
| Bore Diameter | <32 mm> |
| Direction Code | Push Down Left-hand Rotation |
| Rotation Angle Code | <90°> |
