Airtac ACKDR Rotary Cylinder ACKDR25X90
2. Triple guide groove structure delivers enhanced guiding precision;
3. Configurable with single-side and double-side (90°) operation modes;
4. Offers left-handed/right-handed rotation options with 90° or 180° angular strokes;
5. Heat-treated piston rod manufactured from special alloy steel guarantees prolonged service life.
Category: Angular Cylinders | Brand: AirTAC | Series: ACKDR
AirTAC ACKDR25X90 Rotary Table Actuator Specifications
- Model: ACKDR25X90
- Type: Compact rotary cylinder (rack-and-pinion design)
- Bore size: 25mm
- Rotation angle: 90° (±5° adjustable)
- Operating pressure: 0.1–0.8 MPa
- Mounting options: Side mounting (ISO 15552 standard) / flange mounting
- Port size: M5x0.8 (dual ports for bidirectional control)
- Cushioning: Adjustable pneumatic cushion
- Body material: Aluminum alloy (anodized finish)
- Piston rod: Stainless steel (SUS304)
- Seal material: Heat-resistant NBR (-20℃ to 100℃)
- Weight: 1.2kg (without accessories)
- Dimensions: 105mm(L) × 76mm(W) × 76mm(H)
- Torque output: 2.8 N·m @ 0.4 MPa
- Repeat accuracy: ±0.2°
- Protection rating: IP40 (dust protected)
High-precision 90-degree rotary actuator designed for space-constrained automation systems. Features dual internal shock absorbers and anti-rotation pins for stable angular positioning. The corrosion-resistant construction allows operation in humid environments (non-lubricated air compatible). Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 standards.
- Part orientation in robotic assembly lines
- Workpiece flipping in CNC machine tending
- Valve actuation in food processing equipment
- Camera/Sensor positioning in inspection systems
- Pallet rotating mechanisms in packaging
Installation tips:
Maintain ≤0.5mm alignment tolerance during mounting. Use dynamic load calculations when handling payloads >3kg.
Lubricate pivot points every 500,000 cycles (use ISO VG32 pneumatic oil). Avoid side-load forces exceeding 15N.
| Property | Property Value |
|---|---|
| sku | ACKDR25X90 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Bore Diameter | <25 mm> |
| Direction Code | Press-down Right-hand |
| Rotation Angle Code | <90°> |
