Airtac ACKDR Rotary Cylinder ACKDR40X90
2. Triple guide groove structure delivers enhanced guiding precision;
3. Configurable with single-side and double-side (90°) operation modes;
4. Offers left-handed/right-handed rotation options with 90° or 180° angular strokes;
5. Heat-treated piston rod manufactured from special alloy steel guarantees prolonged service life.
Category: Angular Cylinders | Brand: AirTAC | Series: ACKDR
AirTAC ACKDR40X90 Rotary Clamp Cylinder Specifications
- Model: ACKDR40X90
- Type: Double-acting rotary clamp cylinder (90° rotation)
- Bore size: 40mm
- Stroke: 90mm
- Rotation angle: 90°±1° (clock/counter-clockwise selectable)
- Operating pressure: 0.1–0.8 MPa
- Piston speed: 50–700 mm/s
- Mounting style: Side lug or front flange
- Body material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel (Cr plating optional)
- Buffer type: Adjustable cushioning
- Temperature range: -10℃ to 80℃
- Weight: 1.85 kg
- Dimensions: 150mm(L) × 42mm(W) × 42mm(H)
- Port size: M5x0.8 (1/8" NPT adaptor available)
- Torque output: 1.2 N·m @ 0.5 MPa
- Repeat positioning accuracy: ±0.5°
Compact rotary actuator combining linear motion with 90° angular rotation, featuring precision ground helical gears and maintenance-free guide bushings. The nickel-plated piston rod and wear-resistant seals ensure >3 million cycles lifespan. Includes magnetic piston for position sensing compatibility.
- Workpiece flipping in CNC machine tending
- 90° part orientation in assembly lines
- Clamping & rotating fixtures for welding stations
- Material transfer between conveyor systems
- Precision angular positioning in semiconductor handling
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use. Maintain 0.3mm minimum clearance between magnetic sensor and cylinder body. Avoid side loads exceeding 20N during operation.
| Property | Property Value |
|---|---|
| sku | ACKDR40X90 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
| Direction Code | Press-down Right-hand |
| Rotation Angle Code | <90°> |
