Airtac ACKDR Rotary Cylinder ACKDR63X90
2. Triple guide groove structure delivers enhanced guiding precision;
3. Configurable with single-side and double-side (90°) operation modes;
4. Offers left-handed/right-handed rotation options with 90° or 180° angular strokes;
5. Heat-treated piston rod manufactured from special alloy steel guarantees prolonged service life.
Category: Angular Cylinders | Brand: AirTAC | Series: ACKDR
AirTAC ACKDR63X90 Rotary Clamp Cylinder Specifications
- Model: ACKDR63X90
- Type: Compact rotary clamping cylinder (double-acting)
- Bore size: 63mm
- Stroke: 90mm
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: 1/4" NPT (G1/8 optional)
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Through-hole base mounting
- Material: Aluminum alloy body, NBR seals
- Weight: 2.5kg ±3%
- Dimensions: 150mm(L) × 63mm(W) × 63mm(H)
- Rotation angle: 90° ±1° (fixed)
- Repeat positioning accuracy: ±0.5°
- Max lateral load: 150N
- Protection rating: IP54 (standard)
High-precision rotary actuator combining linear thrust and angular motion, featuring integrated guide rails for smooth 90° workpiece rotation. Anti-vibration design with hardened steel shafts ensures positional stability in high-cycle applications. Includes built-in magnetic sensor slots (PNP/NPN configurable).
- Automated part flipping in assembly lines
- Pallet positioning in CNC machining centers
- Orientation correction in packaging machinery
- Fixture rotation in welding stations
- PCB board handling in electronics manufacturing
Installation note:
Ensure proper alignment of rotation plane with workpiece center of gravity.
Lubricate guide rails every 500,000 cycles using ISO VG32 hydraulic oil.
Max permissible side load must not exceed 10% of axial thrust capacity.
| Property | Property Value |
|---|---|
| sku | ACKDR63X90 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | PT1/8 |
| Bore Diameter | 63mm |
| Direction Code | Press-down Right-hand |
| Rotation Angle Code | <90°> |
