This model is discontinued
AirTAC has phased out the ACP series. You can still order this code here: we ship the current replacement ACE100X10, the same code under the new prefix. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACP Compact Cylinder ACP100X10
The AirTAC ACP Compact Cylinder ACP100X10 is a double acting DIN-standard tight/compact air cylinder with a Ø100mm bore and 10mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACE100X10 (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke10 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM16×1.5
- StatusDiscontinued → ACE100X10
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACP Compact Cylinder ACP100X10
A double acting compact cylinder in the DIN-standard ACP series, the ACP100X10 pairs a 100 mm bore with a 10 mm stroke and delivers 3927 N push and 3681.6 N pull at 0.5 MPa, rising to 5497.8 N push at 0.7 MPa. The short ISO 21287-class body cuts roughly 50% of the mounting length of an ISO 15552 profile cylinder, so a heavy-duty ram fits where a full-length body cannot. Air supply runs 0.15-1.0 MPa (22-145 psi) with rod speed from 30-500 mm/s.
Construction is a hard-anodized aluminium body with an S45C hard-chrome 25 mm rod, M16x1.5 female rod thread and a 1/4" port, with a fixed TPU bumper at each end. This model is discontinued: the current-production direct is ACE100X10, so confirm the ISO 21287 mounting dimensions before swapping.
Airtac ACP Compact Cylinder ACP100X10 Technical Specifications
| Model | Airtac ACP Compact Cylinder ACP100X10 |
|---|---|
| Series | ACP DIN compact cylinder (discontinued) |
| Replacement | ACE100X10 |
| Bore size | Ø100 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACE100X10 (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | 5154 N |
| Max (@1.0 MPa) | 801 kgf | |
The ACE100X10 produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac ACP Compact Cylinder ACP100X10
| ACP | DIN compact cylinder (double-acting, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).
Where the Airtac ACP Compact Cylinder ACP100X10 Is Used
Short-stroke press head
The 3927 N push at 0.5 MPa drives a compact crimping or stamping head on an electronics assembly line where only 10 mm of travel is needed.
Machine tool clamp
Clamps a steel fixture on a CNC milling table; the short body slots into the fixture base where a full-length cylinder would overhang.
Palletizer push-off
Kicks cartons off a conveyor stop at up to 500 mm/s, with the 1/4" port feeding the high flow a 100 mm bore demands.
Replacing the Airtac ACP Compact Cylinder ACP100X10 with the ACE100X10
For a 10 mm stroke at this force class, 3927 N push at 0.5 MPa covers heavy clamping and short-press work; step down to the 80 mm bore (2513.3 N push) for lighter loads or accept that no larger ACP bore exists. Note that a plain cylinder drifts when air is lost, so add a rod lock or pilot check valve if the load must stay put. Order the -S code if you need the optional magnet for CMSE / DMSE switches; without it no sensor can be fitted. FA/FB flange, LB foot and CA/CB clevis mountings bolt to the standard face. This model is discontinued and replaced by ACE100X10.
Replacement checklist
- ✓ Current-production ACE → ACE100X10
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACP Compact Cylinder ACP100X10 FAQ
Push is 3927 N and pull 3681.6 N at 0.5 MPa; at 0.7 MPa push reaches 5497.8 N, with a theoretical maximum of 800.9 kgf at 1.0 MPa. It is double acting, 100 mm bore, 10 mm stroke, 25 mm rod with M16x1.5 female thread, 1/4" port, operating pressure 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-500 mm/s, temperature -20 to +70 C, with a fixed TPU bumper at both ends.
Order ACE100X10, the current-production ISO 21287 successor: swap the P for an E and you get the same bore, stroke and force class in a matching short body. Because the ACP was built to a DIN standard, confirm the ISO 21287 mounting dimensions before swapping. If you need position sensing, the ACE takes the same optional-magnet approach with CMSE / DMSE switches.
