This model is discontinued
AirTAC has phased out the ACP series. You can still order this code here: we ship the current replacement ACE100X100B, the same code under the new prefix. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACP Compact Cylinder ACP100X100B
The AirTAC ACP Compact Cylinder ACP100X100B is a double acting DIN-standard tight/compact air cylinder with a Ø100mm bore and 100mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACE100X100B (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke100 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM16×1.5
- StatusDiscontinued → ACE100X100B
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACP Compact Cylinder ACP100X100B
The ACP100X100B is a double acting DIN-standard compact cylinder with a 100 mm bore and 100 mm stroke, built on a hard-anodized aluminium body with a 25 mm S45C hard-chrome piston rod. Air drives the rod in both directions, and fixed TPU bumpers at each end absorb end-of-travel shock. At 0.5 MPa it pushes with 3927 N and pulls with 3681.6 N; at 0.7 MPa those figures rise to 5497.8 N and 5154.2 N, with a theoretical peak of 800.9 kgf at 1.0 MPa. The short ISO 21287-class body saves roughly 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into heavy presses, clamping gantries and machine frames where a full-length body will not fit.
The B code gives a male rod thread; the 1/4" port depends only on the 100 mm bore. This model is discontinued - the current-production direct is the ACE100X100 in the same bore, stroke and force class, so confirm ISO 21287 mounting dimensions before swapping. Operating range is 0.15-1.0 MPa (22-145 psi), speed 30-500 mm/s, temperature -20 to +70 C.
Airtac ACP Compact Cylinder ACP100X100B Technical Specifications
| Model | Airtac ACP Compact Cylinder ACP100X100B |
|---|---|
| Series | ACP DIN compact cylinder (discontinued) |
| Replacement | ACE100X100B |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACE100X100B (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | 5154 N |
| Max (@1.0 MPa) | 801 kgf | |
The ACE100X100B produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac ACP Compact Cylinder ACP100X100B
| ACP | DIN compact cylinder (double-acting, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).
Where the Airtac ACP Compact Cylinder ACP100X100B Is Used
Heavy clamping on CNC fixtures
The 3927 N push at 0.5 MPa clamps steel billets and weldments in machining fixtures, with the 100 mm stroke clearing the part for loading.
Press and forming stations
With up to 5497.8 N at 0.7 MPa, the bore suits light staking, riveting and forming heads where a full-length body would overhang the frame.
Replacing the Airtac ACP Compact Cylinder ACP100X100B with the ACE100X100B
Size against the 3927 N push at 0.5 MPa: if your load needs less, the ACP80X100B delivers 2513.3 N in the same stroke; if you need more headroom, no larger bore exists in this family, so step up pressure instead. Remember a plain ACP does not hold position when air is lost - the piston drifts - so add a rod lock or pilot check valve for held loads. Mounting brackets FA/FB flange, LB foot, CA/CB clevis, CR, SDB pivot and FTC bolt to the standard face, and I/Y rod knuckles suit the male thread. The optional -S magnet enables CMSE / DMSE switches; without -S there is no magnet. Order the ACE100X100 as the current replacement.
Replacement checklist
- ✓ Current-production ACE → ACE100X100B
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACP Compact Cylinder ACP100X100B FAQ
At 0.5 MPa it pushes 3927 N and pulls 3681.6 N. At 0.7 MPa it pushes 5497.8 N and pulls 5154.2 N. The theoretical maximum is 800.9 kgf at 1.0 MPa. It is double acting, so air extends and retracts the 25 mm rod, and speed runs 30-500 mm/s over 0.15-1.0 MPa (22-145 psi).
Order the ACE100X100: swap the P for an E and you get the current-production ISO 21287 compact cylinder in the same 100 mm bore, 100 mm stroke and force class. Because the ACP is DIN-standard, confirm the ISO 21287 mounting dimensions against your fixture before the swap. If you need position sensing, the ACE takes the same optional-magnet approach with CMSE / DMSE switches.
