This model is discontinued

AirTAC has phased out the ACP series. You can still order this code here: we ship the current replacement ACE100X15S, the same code under the new prefix. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.

AirTAC ACP Series · Discontinued Compact Cylinder

Airtac ACP Compact Cylinder ACP100X15S

The AirTAC ACP Compact Cylinder ACP100X15S is a double acting DIN-standard tight/compact air cylinder with a Ø100mm bore and 15mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACE100X15S (ISO 21287 ACE), in the same bore, stroke and force class.

  • BoreØ100 mm
  • Stroke15 mm
  • Port size1/4"
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • StatusDiscontinued → ACE100X15S
$153.91 $167.98Save 8% Ships as ACE100X15S (current AirTAC replacement)
Ships as ACE100X15S, the current AirTAC replacement (the same code under the new prefix). Order this code as usual. Your cart, checkout and order confirmation will show the ACE100X15S we ship. View ACE100X15S
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every ACP100 stroke, mounting and version on one page All ACP100 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac ACP Compact Cylinder ACP100X15S

A double acting compact cylinder with a 100 mm bore and a short 15 mm stroke, the ACP100X15S pushes with 3927 N and pulls with 3681.6 N at 0.5 MPa, rising to 5497.8 N at 0.7 MPa. Its hard-anodized aluminium body and S45C hard-chrome rod are built to the DIN-standard compact format, and the short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into heavy clamping fixtures where a full-length body will not fit. The -S code on this model means the magnet is fitted, so CMSE or DMSE reed and solid-state switches can be mounted directly on the tube.

A fixed TPU bumper sits at both ends of the stroke, and the piston drifts if air is lost, so add a rod lock or pilot check valve where a load must stay put. This model is discontinued: the current-production direct is the ISO 21287 ACE100X15, same bore, stroke and force class - confirm the ISO 21287 mounting dimensions before swapping, since the ACP follows the DIN-standard footprint.

Airtac ACP Compact Cylinder ACP100X15S Technical Specifications

ModelAirtac ACP Compact Cylinder ACP100X15S
SeriesACP DIN compact cylinder (discontinued)
ReplacementACE100X15S
Bore sizeØ100 mm
Stroke15 mm
Acting typeDouble acting
Port size1/4"
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed bumper (both ends)
Max standard strokeUp to 300 mm

Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACE100X15S (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.

Theoretical Output Force (Ø100mm)

PressurePush forcePull force
0.5 MPa3927 N3682 N
0.7 MPa5498 N5154 N
Max (@1.0 MPa)801 kgf

The ACE100X15S produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.

Model Code: Airtac ACP Compact Cylinder ACP100X15S

ACPDIN compact cylinder (double-acting, discontinued).
100Bore size in mm.
×15Stroke length in mm.
SOptional built-in magnet for sensor position sensing (omit for no magnet).
BRod type: B = male thread; blank = female thread.

Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).

Where the Airtac ACP Compact Cylinder ACP100X15S Is Used

compress

Press die clamping

The 3927 N push at 0.5 MPa clamps stamping or forging dies on a 100-ton press, with the 15 mm stroke locking the die block in seconds and the CMSE switch confirming clamp-on via the fitted magnet.

factory

Injection mold slide core

Short-stroke core pulls on an injection mold use the 3681.6 N pull force at 0.5 MPa to retract a steel slide, with the compact body fitting inside the mold shoe where a full-length body cannot.

Replacing the Airtac ACP Compact Cylinder ACP100X15S with the ACE100X15S

At 100 mm bore this is the top of the ACP range, delivering 3927 N push at 0.5 MPa; if your load needs under 2513 N, the 80 mm bore gives that figure at the same pressure and a shorter body. The 15 mm stroke suits short-throw clamping or ejection rather than long transfer moves - standard strokes for this bore run up to 300 mm, so longer throws stay standard. Mount with FA/FB flange, LB foot or CA/CB clevis brackets, and remember this unit already carries the optional -S magnet for CMSE / DMSE switches. Order the ACE100X15 as the current replacement and verify ISO 21287 mounting dimensions first.

Replacement checklist

  • ✓ Current-production ACE → ACE100X15S
  • ✓ Same bore / stroke / force class
  • ✓ Confirm ISO 21287 mounting dimensions
  • ✓ Port/thread type (PT / G)
  • ✓ Add -S for magnet if you need sensors
View ACE100X15S

Airtac ACP Compact Cylinder ACP100X15S FAQ

At 0.5 MPa it pushes 3927 N and pulls 3681.6 N; at 0.7 MPa push rises to 5497.8 N and pull to 5154.2 N. Theoretical maximum at 1.0 MPa is 800.9 kgf. Operating range is 0.15-1.0 MPa (22-145 psi) with 1.5 MPa (215 psi) proof pressure, speed 30-500 mm/s, and a 1/4" port. Note the piston drifts when air is lost - use a rod lock or pilot check valve to hold a load.

Order the ACE100X15, the ISO 21287 successor made by swapping the P for an E: same 100 mm bore, 15 mm stroke and force class, with a matching short body and mounting family. Because the ACP is DIN-standard, confirm the ISO 21287 mounting dimensions before the swap. The ACE family also covers related variants such as single-acting ASP/ATP, double-rod ACPD and adjustable ACPJ types.
