Airtac ACP Compact Cylinder ACP100X15SB
2. Enhanced structural integrity with threaded end covers for superior strength and maintenance accessibility;
3. Barrel interior features precision machining with hard anodized treatment for exceptional wear resistance and durability;
4. Specialized bidirectional sealing structure on piston ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact design for efficient spatial utilization in installations;
6. Perimeter grooves for magnetic sensor switch mounting with tool-free installation convenience;
7. Multiple mounting accessory configurations available for flexible adaptation;
Category: Compact Cylinders | Brand: AirTAC | Series: ACP
AirTAC ACP100X15SB Compact Cylinder Specifications
- Model: ACP100X15SB
- Type: Double-acting compact cylinder
- Bore size: Φ100mm
- Stroke: 15mm
- Operating pressure: 0.1–0.9 MPa
- Port size: G1/2 (Rc1/2 optional)
- Cushioning: Adjustable air cushion (both ends)
- Piston speed: 50–700 mm/s
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy barrel, CRCA mounting bracket
- Seal material: NBR (Nitrile rubber)
- Weight: 2.8 kg (with standard accessories)
- Dimensions: 200mm(L) × 100mm(W) × 100mm(H)
- Mounting type: Basic foot mounting (ISO 15552 compatible)
- Repetition accuracy: ±0.5mm
- Lubrication: Pre-lubricated (Oil-free operation possible)
The ACP100X15SB features a space-saving design with 30% reduced length compared to standard cylinders, while maintaining high thrust force (706N at 0.6MPa). Its anodized surface treatment enhances corrosion resistance, and the dual-piston design ensures smooth operation. The cylinder incorporates a magnetic piston for position sensing compatibility (sensor not included).
- High-density automation assembly lines
- Precision clamping in CNC tool changers
- Vertical lifting mechanisms in packaging machinery
- Position adjustment in semiconductor handling equipment
- Robotic end-effector actuation systems
Installation recommendations:1. Use M6 mounting screws with 12mm minimum engagement
2. Maintain 0.5-1mm clearance between magnetic sensor and cylinder axis
3. For vertical mounting, install lock nuts on piston rod end
4. Lubricate every 3 months with ISO VG32 hydraulic oil if used in oil mist lubrication systems
- Minimum start pressure: 0.08 MPa
- Maximum permissible lateral load: 120N
- Cycle life: 5,000 km (at 0.5MPa, 50mm/s)
- Air consumption: 0.47L/stroke (at 0.6MPa)
| Property | Property Value |
|---|---|
| sku | ACP100X15SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <15mm> |
