Airtac ACQ Ultra Thin Air Cylinder ACQ12X10SBH
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X10SBH Ultra-Thin Cylinder Specifications
- Model: ACQ12X10SBH
- Type: Double-acting ultra-slim cylinder
- Bore size: 12mm
- Stroke: 10mm
- Operating pressure: 0.1–0.9 MPa
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable rubber buffer
- Piston speed: 50–800 mm/s
- Temperature range: -20℃ to 80℃
- Seal material: NBR (nitrile rubber)
- Body material: Anodized aluminum alloy
- Rod material: Stainless steel (SUS304)
- Mounting style: Basic type (optional foot/mounting bracket)
- Weight: 0.12kg ±5%
- Dimensions: 56mm(L) × 34mm(W) × 12mm(H)
- Protection rating: IP54 (standard)
- Lubrication: Required (ISO VG32 or equivalent)
The ACQ12X10SBH features a revolutionary 6mm-thick cylinder body design, achieving 40% space savings compared to standard models. Its low-friction structure enables precise position control (repeatability ±0.5mm) while maintaining 30% higher lateral load capacity than conventional slim cylinders. Includes integrated magnet for sensor mounting.
- High-density SMT component placement machines
- Medical device actuation systems (e.g., surgical robots)
- Compact packaging machinery with space constraints
- Precision optical lens positioning stages
- Desktop automation in semiconductor handling
- Collaborative robot end-effector mechanisms
Installation guidelines:
Maintain ≤0.05mm parallelism tolerance during mounting.
Use C-shaped retaining rings for vertical installations.
Pre-lubricate for initial 500km stroke operation.
Avoid side load exceeding 5N.
| Property | Property Value |
|---|---|
| sku | ACQ12X10SBH |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
