Airtac ACQ Ultra Thin Air Cylinder ACQ12X15
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X15 Ultra-Thin Cylinder Technical Specifications
- Model: ACQ12X15
- Bore size: 12mm
- Stroke: 15mm
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer
- Port size: M5x0.8 (1/8" NPT optional)
- Piston speed: 50–800 mm/s
- Mounting type: Basic type (no built-in mounts)
- Seal material: Polyurethane (NBR optional)
- Rod material: Stainless steel (SUS304)
- Tube material: Aluminum alloy (anodized)
- Weight: 0.18kg ±5%
- Dimensions: 50mm(L) × 32mm(W) × 32mm(H)
- ISO standard: 6432 (compact cylinder specifications)
The ACQ12X15 represents AirTAC's ultra-compact cylinder solution featuring a 30% slimmer profile than standard ISO 6432 cylinders. Precision-machined with dual piston seals for leak-proof operation, it delivers 23N thrust at 0.5MPa. The chrome-plated piston rod integrates wear-resistant guide bands for smooth linear motion. Requires 0.1–1.0 μm filtered air with oil mist lubrication (NBR seals) or dry air (polyurethane seals).
- PCB handling robots in electronics manufacturing
- Micro-positioning stages in semiconductor FOUP openers
- Medical device clamp mechanisms
- Compact jig actuators for watch assembly
- Automated lens positioning in optical equipment
- Packaging machine gate controls
Installation guidance:
For vertical mounting, reduce maximum speed by 30% to prevent piston chatter.
Maintain 0.5mm minimum lateral clearance during side-load applications.
Lubricate through port using ISO VG32 turbine oil during initial setup.
| Property | Property Value |
|---|---|
| sku | ACQ12X15 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
