Airtac ACQ Ultra Thin Air Cylinder ACQ12X15H
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X15H Ultra-Thin Cylinder Technical Details
- Model: ACQ12X15H (Compact Series)
- Bore size: 12mm (ISO 6432 standard)
- Stroke: 15mm ±0.5mm
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5x0.8 (Dual ports, 2x intake/exhaust)
- Cushioning type: Fixed rubber buffer
- Mounting style: Basic front flange (MF1)
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Seal type: NBR rubber (FDA compliant option available)
- Weight: 0.18kg (without accessories)
- Dimensions: 52mm(L) × 40mm(W) × 25.5mm(H) (at fully retracted position)
- Rod thread: M4x0.7 (Female)
- Max theoretical thrust: 11.3N @0.5MPa
- ISO speed range: 50–500mm/s
- Lubrication: Pre-lubricated (Grease-free operation)
This space-saving pneumatic cylinder features a 60% slimmer profile than standard models while maintaining 0.8MPa pressure tolerance. The nickel-plated end caps and integrated guide structure prevent rotation during operation. Optimized for vertical/horizontal mounting in clean environments with 0.1μm filtered air. Includes built-in auto-adjust wear compensation.
- PCB board clamping in SMT machinery
- Micro-precision positioning in semiconductor handlers
- Paper feed mechanisms in compact printers
- Medical device actuation (IV pump mechanisms)
- Robotic end-effector tool changers
Installation guidance:
Use C-shaped mounting brackets (sold separately) for vibration-prone applications.
Maintain 0.3-0.5mm clearance between rod end and load during alignment.
Lubricate every 500km stroke travel with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | ACQ12X15H |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
