Airtac ACQ Ultra Thin Air Cylinder ACQ12X20
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ Series Ultra-Thin Cylinder ACQ12X20 Technical Details
- Model: ACQ12X20
- Bore size: 12mm (ISO 6432 standard)
- Stroke: 20mm (±1mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Fixed rubber buffer
- Mounting style: Basic (no built-in mounts)
- Port size: M5x0.8 (dual ports)
- Piston rod thread: M5x0.8 (external)
- Material: Aluminum alloy body, stainless steel piston rod
- Seals: NBR (standard), optional FKM for high temp
- Weight: 85g (without accessories)
- Dimensions:
- Length: 65mm (full retraction)
- Width: 28mm (body diameter)
- Height: 28mm (square profile)
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (Grease G-30)
This space-saving cylinder features a 40% reduced cross-section compared to standard models, optimized for machinery with dimensional constraints. The anodized surface treatment enhances corrosion resistance, while the precision-ground rod ensures smooth linear motion. Requires 0.5-1.5μm filtered air and periodic relubrication every 3 million cycles.
- PCB handling robots in electronics assembly
- Medical device clamping mechanisms
- Photocopier paper feed systems
- Compact packaging machines
- Cleanroom automation (low particle emission)
- Beverage canning line actuators
Installation tip:
Maintain 0.5mm minimum clearance between cylinder body and adjacent components to prevent thermal expansion interference. Use Cushion screw adjuster (optional ACQ-ADJ accessory) for precise end-position damping.
| Property | Property Value |
|---|---|
| sku | ACQ12X20 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
